Siirry sivupalkkiinSiirry alaosaanClaas Dominator 56-106

The first small Dominators 56 and 76 were introduced in 1978. Their features included a new table lightening, a hydraulically foldable unloading auger, and open threshers. In 1979, the 66 was introduced between the 56 and 76, which was a 6-cylinder version of the 56. These models had a new cab with tinted windows and an optional heater. The design was very modern and stylish. The 76 was also available as a hillside threshing version, the 76 H.
The Dominator 106 and the slightly later introduced 96 were successors to the Dominator 105. However, only the 106 had 6 threshing elements. The Dominator 86 replaced the Dominator 85 in 1980. The 56 and 66 were already replaced in 1982 by the new 58 and 68 models.
This is an automated translation. Please report any issues in the translation.
| Model | Claas Dominator 56 | Claas Dominator 66 | Claas Dominator 76 | Claas Dominator 86 | Claas Dominator 96 | Claas Dominator 106 |
|---|---|---|---|---|---|---|
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 1978-82 | 1979-82 | 1978-85 | 1980-85 | 1978-85 | 1978-85 |
| Engine | Perkins | Perkins | Perkins | Perkins | MB | MB |
| Engine type | 4.236 | 6.3544 | 6.372 | 6.372 | OM 352 | OM 352 |
| Displacement | 3860 cm³ | 5797 cm³ | 6100 cm³ | 6100 cm³ | 5675 cm³ | 5675 cm³ |
| Cyl/turbo | 4 | 6 | 6 | 6 | 6 T | 6 T |
| Power | 80 hp DIN | 100 hp DIN | 120 hp DIN | 120 hp DIN | 150 hp DIN | 170 hp DIN |
| Fuel tank | 200 l | 200 l | 200 l | 300 l | 300 l | 300 l |
| Transmission | mech. | mech. | mech. | mech. | mech. | hydr. |
| Gears | 3 | 3 | 3 | 3 | 3 | 3 |
| Speed min-max. | 1,9-21 km/h | 1,9-21 km/h | 1,6-19,9 km/h | 1,6-19,9 km/h | 1,6-19,9 km/h | 0-20 km/h |
| Cutting width | 360 cm | 360 cm | 390 cm | 500 cm | 500 cm | 500 cm |
| Cutting width, alternative | 270-390 cm | 300, 390 cm | 300-450 cm | 390, 450 cm | 390, 450 cm | 450 cm |
| Reel diameter | 105 cm | 105 cm | 105 cm | 105 cm | 105 cm | 105 cm |
| Header length | 48 cm | 48 cm | 48 cm | 48 cm | 48 cm | 48 cm |
| Threshing cyl. diameter | 45 cm | 45 cm | 45 cm | 45 cm | 45 cm | 45 cm |
| Threshing cyl. width | 106 cm | 106 cm | 106 cm | 132 cm | 132 cm | 158 cm |
| Number of straw walkers | 4 | 4 | 4 | 5 | 5 | 6 |
| Area of walkers | 415 dm² | 415 dm² | 466 dm² | 515 dm² | 580 dm² | 695 dm² |
| Lenght of walkers | 390 cm | 390 cm | 440 cm | 390 cm | 440 cm | 440 cm |
| Straw shieve | 173 dm² | 173 dm² | 173 dm² | 192 dm² | 192 dm² | 270 dm² |
| Bottom shieve | 119 dm² | 119 dm² | 119 dm² | 140 dm² | 140 dm² | 240 dm² |
| Total screening area | 340 | 340 | 340 | 425 | 425 | 510 |
| Overall lenght | 975 cm | 975 cm | 1054 cm | 1000 cm | 1050 cm | 1050 cm |
| Width without header | 300 cm | 300 cm | 300 cm | 300 cm | 300 cm | 300 cm |
| Height without cabin | 339 cm | 339 cm | - | - | - | - |
| Weight without cabin | 6900 kg | 7360 kg | 7710 kg | 8130 kg | 8200 kg | - |
| Grain tank | 25 hl | 25 hl | 42 hl | 46 hl | 52 hl | 65 hl |
| Tyres front (Finland) | 23.1-26 | 23.1-26 | 23.1-26 | 23.1-26 | 23.1-26 | 23.1-26 |
| Tyres front, alternative | 18.4-26 | 18.4-30 | 18.4-30 | 28.1-26 | 28.1-26 | 28.1-26 |
| Tyres rear (Finland) | 12.5-18 | 12.5-18 | 12.5-18 | 14.5-20 | 14.5-20 | 14.5-20 |
| Tyres rear, alternative | 10.00-12 | 11.5/80-15 | 11.5/80-15 | 12.5-18 | 12.5-18 | - |
| Reel forward/backw. adjustment | mech. | mech. | mech. | mech. | mech. | mech. |
| Reel speed adjustment | adj, in cabin | adj, in cabin | adj, in cabin | hydr. | hydr. | hydr. |
| Threshing cyl. speed adjustment | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Bottom sieve | adj. | adj. | adj. | adj. | adj. | adj. |
| Brakes | hydr. drum | hydr. drum | hydr. drum | hydr. drum | hydr. drum | hydr. drum |
| Type of cutting platform floating | spring | spring | spring | spring | spring | spring |
| Alternative hp | - | - | 150 (MB) hp | 150 (MB) hp | 170 hp | 205 hp |
| Height with cabin | - | - | 371 cm | 370 cm | 370 cm | 373 cm |
| Weight with cabin | - | - | 8500 kg | 9200 kg | - | 9500 kg |
| Slope levelling | - | - | opt. | - | - | - |
