John Deere 1133 – 1158
Manufacturer
Models
John Deere 1133, John Deere 1144, John Deere 1155, John Deere 1155-6, John Deere 1157, John Deere 1158
Years
1989-95
Info
At the end of 1989, the smaller models of JD's 1000 series were replaced by the 1100 series models. From the 1155 model onwards, the cutting table was from the new 800 series, where the table length and base incline were adjustable. Similarly, starting with the 1155, the equipment included a cross auger above the grain pan and a new 4-speed transmission. The smallest models, 1133 and 1144, were still mainly produced for the Nordic markets. They remained JD's last small combines. The 1144 also now came with the SG2 cab.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | John Deere 1133 | John Deere 1144 | John Deere 1155 | John Deere 1155-6 | John Deere 1157 | John Deere 1158 |
|---|---|---|---|---|---|---|
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 1989-91 | 1989-94 | 1989-93 | 1991-95 | 1989-94 | 1989-94 |
| First year sold | 1989 | 1989 | 1989 | 1991 | 1989 | 1989 |
| Last year sold | 1991 | 1994 | 1993 | 1995 | 1994 | 1994 |
| Power | 65 | 75 | 85 | 105 | 105 | 115 |
| Engine | JD | JD | JD | JD | JD | JD |
| Engine type | 4239 DZ03 | 4239 DZ05 | 4239 TZ04 | 6539 DZ03 | 6539 DZ03 | 6539 TZ03 |
| Displacement | 3920 cm³ | 3920 cm³ | 3920 cm³ | 5883 cm³ | 5883 cm³ | 5883 cm³ |
| Cyl/turbo | 4 | 4 | 4 T | 6 | 6 | 6 T |
| Power hp DIN | 65 | 75 | 85 | 105 | 105 | 115 |
| Fuel tank | 110 l | 110 l | 175 l | 175 l | 175 l | 175 l |
| Transmission | mech. | mech. | mech. | mech. | mech. | mech. |
| Gears | 3 | 3 | 4 | 4 | 4 | 4 |
| Speed min-max. | 1,2-20 km/h | 1,2-20 km/h | 1,2-20 km/h | 1,2-20 km/h | 1,2-20 km/h | 1,2-20 km/h |
| Cutting width | 265 cm | 305 cm | 365 cm | 365 cm | 365 cm | 365 cm |
| Cutting width, alternative | 305 cm | 265 cm | 305 cm | 305 cm | 425 cm | 425 cm |
| Reel diameter | 110 cm | 110 cm | 110 cm | 110 cm | 110 cm | 110 cm |
| Header length | 36 cm | 36 cm | 37-47 cm | 37-47 cm | 37-47 cm | 37-47 cm |
| Threshing cyl. diameter | 61 cm | 61 cm | 61 cm | 61 cm | 61 cm | 61 cm |
| Threshing cyl. width | 104 cm | 104 cm | 104 cm | 104 cm | 104 cm | 104 cm |
| Number of straw walkers | 4 | 4 | 4 | 4 | 4 | 4 |
| Area of walkers | 306 dm² | 306 dm² | 390 dm² | 390 dm² | 390 dm² | 390 dm² |
| Lenght of walkers | 294 cm | 294 cm | 375 cm | 375 cm | 375 cm | 375 cm |
| Straw shieve | 132 dm² | 132 dm² | 165 dm² | 165 dm² | 165 dm² | 165 dm² |
| Bottom shieve | 98 dm² | 98 dm² | 120 dm² | 120 dm² | 120 dm² | 120 dm² |
| Total screening area | 252 | 252 | 307 | 307 | 307 | 307 |
| Overall lenght | 772 cm | 772 cm | 880 cm | 880 cm | 880 cm | 880 cm |
| Overall width | 300 cm | 300 cm | 405 cm | 405 cm | 405 cm | 405 cm |
| Width without header | - | - | 294 cm | 294 cm | 294 cm | 294 cm |
| Height without cabin | 341 cm | 341 cm | - | - | - | - |
| Height with cabin | 379 cm | 379 cm | 378 cm | 378 cm | 378 cm | 378 cm |
| Weight without cabin | 5180 kg | 5300 kg | - | - | - | - |
| Weight with cabin | - | 5850 kg | 7720 kg | 7720 kg | 7980 kg | 7980 kg |
| Weight without header | - | - | 6640 kg | 6640 kg | 6900 kg | 6900 kg |
| Grain tank | 21 hl | 21 hl | 30 hl | 30 hl | 35 hl | 35 hl |
| Unl. height | 290 cm | 290 cm | 322 cm | 322 cm | 322 cm | 322 cm |
| Tyres front (Finland) | 16.9R26 | 18.4R26 | 23.1-26 | 23.1-26 | 23.1-26 | 23.1-26 |
| Tyres front, alternative | 18.4R26 | 16.9-24 | 18.4-30 | 18.4-30 | 28.1-26 | 28.1-26 |
| Tyres rear (Finland) | 10.5-18 | 10.5-18 | 10.5-18 | 10.5-18 | 13/65-18 | 13/65-18 |
| Tyres rear, alternative | 7.50-16 | 7.50-16 | 12.5/80-18 | 12.5/80-18 | 12.5/80-18 | 12.5/80-18 |
| Reel forward/backw. adjustment | mech. | mech. | mech. | mech. | hydr. | hydr. |
| Reel speed adjustment | adj, in cabin | adj, in cabin | elec. | elec. | elec. | elec. |
| Threshing cyl. speed adjustment | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin |
| Bottom sieve | adj. | adj. | adj. | adj. | adj. | adj. |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Heating | x | x | x | x | x | x |
| Slope levelling | - | - | x | x | x | x |
| Type of cutting platform floating | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
