Massey Ferguson 7465-7499

09MF7485
09MF7400ohjaamo
09MF7485
09MF7400ohjaamo
Manufacturer
Models
Massey Ferguson 7465, Massey Ferguson 7475, Massey Ferguson 7480, Massey Ferguson 7485, Massey Ferguson 7490, Massey Ferguson 7495, Massey Ferguson 7497, Massey Ferguson 7499
Years
2006-12
Info

The 7400 series also received a new design and engines at the same time as the 6400 series. Models equipped with SisuDiesels were introduced at the end of 2006, and Perkins engines in early 2007. The 7400 series no longer had the extra power feature. Instead, the engine power was about 5 hp higher than the corresponding models in the 6400 series, and the torque was as much as in the 6400 series with the extra power feature. The front frame was also new in the 7400 series, as were the front axles in the models equipped with SisuDiesels. Noise levels dropped to 70 dB with Perkins engines and 68 dB with SisuDiesels.

In the autumn of 2009, the largest models in the 7400 series, the 7497 and 7499, were introduced, featuring 7.4-liter Sisu engines.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelMassey Ferguson 7465Massey Ferguson 7475Massey Ferguson 7480Massey Ferguson 7485Massey Ferguson 7490Massey Ferguson 7495Massey Ferguson 7497Massey Ferguson 7499
Manufacturer nameMassey FergusonMassey FergusonMassey FergusonMassey FergusonMassey FergusonMassey FergusonMassey FergusonMassey Ferguson
Imported to FinlandYesYesYesYesYesYesYesYes
Years2007-122007-122007-122006-122006-122006-122009-122009-12
Engine model1106D-E66TA1106D-E66TA1106D-E66TA66CTA66CTA66CTA74CTA74CTA
Cyl/Turbo/Intercooler6TI6TI6TI6TI6TI6TI6TI6TI
Displacement6600 cm³6600 cm³6600 cm³6598 cm³6598 cm³6598 cm³7368 cm³7368 cm³
Bore x stroke105×127 mm105×127 mm105×127 mm108×120 mm108×120 mm108×120 mm108×134 mm108×134 mm
Rated power--------
Max power--------
Torque--------
Gearssteplesssteplesssteplesssteplesssteplesssteplesssteplessstepless
Synchronized gearssteplesssteplesssteplesssteplesssteplesssteplesssteplessstepless
Powershift gearssteplesssteplesssteplesssteplesssteplesssteplesssteplessstepless
Reverserhydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.
Speeds in km/h0-40/500-40/500-40/500-40/500-40/500-40/500-40/500-40/50
Max. speed 40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h
Hydr. flow l/min110 l/min110 l/min110 l/min110 (150) l/min110 (150) l/min110 (150) l/min110 (150) l/min110 (150) l/min
Hydraulic pressure200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar
Lift controlselec.elec.elec.elec.elec.elec.elec.elec.
Lift capacity7600 kg7600 kg8600 kg9300 kg9300 kg9300 kg9300 kg9300 kg
PTO speeds540/1000540/1000540/1000540/1000540/1000540/1000540/1000540/1000
Brakeswet discwet discwet discwet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD9.69.61010.310.310.310.310.3
Front tyres 4WD14.9R2814.9R2816.9R2816.9R3016.9R3016.9R30480/70R30480/70R30
Rear tyres 4WD18.4R3818.4R3820.8R3820.8R4220.8R4220.8R42620/70R42620/70R42
Weight 4WD5815 kg6060 kg6345 kg6830 kg6830 kg6940 kg7400 kg7400 kg
Height with cab290 cm290 cm294 cm310 cm310 cm310 cm310 cm310 cm
Length (2WD/4WD)479 cm479 cm479 cm523 cm523 cm523 cm523 cm523 cm
Wheelbase (2WD/4WD)282 cm282 cm282 cm300 cm300 cm300 cm300 cm300 cm
Fuel tank270 l270 l270 l380 l380 l380 l380 l380 l
Cab noise level70 dB70 dB70 dB68 dB68 dB68 dB68 dB68 dB
Solid cabxxxxxxxx
Diff. lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lock
Autom. differential locksxxxxxxxx
Air suspension seatxxxxxxxx
Air conditioningxxxxxxxx
Creeper gearxxxxxxxx
