Siirry sivupalkkiinSiirry alaosaanRenault 461S-851S




In 1980, Renault's mid-range models received the letter S appended to their model designations. At the same time, the color scheme changed to yellow and black. However, the 751S was already introduced in the old colors the previous year. In the S models, the engines’ torque was increased. Road speeds were raised to around thirty kilometers per hour, and except for the smallest model, the number of gears was 12+12. Most models had more lifting power and higher hydraulic output than before. For the models 551S and 651S, Renault developed its own driven front axle. The front axles of the larger four-wheel drives were the same Carraro units with automatic locking differentials as in the MF 600 series. Typical Renault technology still included draft control and dry disc brakes.
The S series was thus a minor update of the lineup introduced in 1974. Sales-wise, the aging lineup clearly lagged behind the late 1970s figures in the 1980s. Before the introduction of new smaller model series, in 1985 the 521S was still brought to market, which had a 2.8-liter engine, 52 hp power, and 2990 kg lifting capacity. To meet the needs of fruit and wine cultivation, Renault offered Carraro tractors as a continuation of its own models based on designs from the 1960s.
This is an automated translation. Please report any issues in the translation.
| Model | Renault 461S | Renault 551S | Renault 651S | Renault 681S | Renault 751S | Renault 781S | Renault 851S |
|---|---|---|---|---|---|---|---|
| Manufacturer name | Renault | Renault | Renault | Renault | Renault | Renault | Renault |
| Imported to Finland | No | No | No | No | No | No | No |
| Years | 1980-87 | 1980-86 | 1980-87 | 1980-86 | 1979-86 | 1980-85 | 1980-89 |
| Engine model | MWM D327-3 | MWM D226-3 | MWM D227-4 | MWM D227-4 | MWM D226-4 | MWM D226-4 | MWM TD226-4 |
| Cyl/Turbo/Intercooler | 3 | 3 | 4 | 4 | 4 | 4 | 4T |
| Displacement | 2827 cm³ | 3117 cm³ | 3770 cm³ | 3770 cm³ | 4154 cm³ | 4154 cm³ | 4154 cm³ |
| Bore x stroke | 100×120 mm | 105×120 mm | 100×120 mm | 100×120 mm | 105×120 mm | 105×120 mm | 105×120 mm |
| Rated power | 46/2150 hp DIN/rpm | 55/2350 hp DIN/rpm | 65/2350 hp DIN/rpm | 68/2350 hp DIN/rpm | 75/2350 hp DIN/rpm | 78/2350 hp DIN/rpm | 85/2350 hp DIN/rpm |
| Torque | - | - | - | - | - | - | - |
| Gears | 10+2 | 12+12 | 12+12 | 12+12 | 12+12 | 12+12 | 12+12 |
| Synchronized gears | 2 | 12+12 | 12+12 | 12+12 | 12+12 | 12+12 | 12+12 |
| Reverser | opt. | mech. | mech. | mech. | mech. | mech. | mech. |
| Speeds in km/h | 0,9-23,4 | 0,7-26,9 | 0,8-28,9 | 0,8-28,7 | 1,3-29,4 | 1,3-29,4 | 1,2-26,8 |
| Hydr. flow l/min | 24.7 l/min | 27.1 l/min | 27.1 l/min | 30.3 l/min | 30.3 l/min | 33 l/min | 33 l/min |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 2500 kg | 2500 kg | 2500 kg | 3850 kg | 3850 kg | 4500 kg | 4500 kg |
| PTO speeds | 540 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Brakes | dry disc | dry disc | dry disc | dry disc | dry disc | dry disc | dry disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 2WD | 6.7 | 6.7 | 6.8 | 8 | 9.8 | 7.6 | 7.6 |
| Front tyres 2WD | 6.00-16 | 6.50-16 | 7.50-16 | 7.50-18 | 9.00-16 | 7.50-18 | 7.50-18 |
| Rear tyres 2WD | 13.6-28 | 14.9-28 | 12.4-36 | 16.9-30 | 13.6-38 | 16.9-34 | 16.9-34 |
| Weight 2WD | 2305 kg | 2415 kg | 2695 kg | 2950 kg | 3120 kg | 3200 kg | 3240 kg |
| Height with cab | 236 cm | 239 cm | 241 cm | 244 cm | 251 cm | 264 cm | 270 cm |
| Length (2WD/4WD) | 345 cm | 352/370 cm | 361/380 cm | 381/397 cm | 383/404 cm | 399/412 cm | 399/412 cm |
| Wheelbase (2WD/4WD) | 210 cm | 211/210 cm | 224/223 cm | 237/241 cm | 237/241 cm | 242 cm | 242 cm |
| Fuel tank | 65 l | 65 l | 65 l | 82 l | 77 l | 77 l | 77 l |
| Cab noise level | 89 dB | 88 dB | 89 dB | 87 dB | 88 dB | - | 85.5 dB |
| Solid cab | x | x | x | x | x | x | x |
| Creeper gear | x | x | x | x | opt. | opt. | opt. |
| Turning circle m 4WD | - | 9.3 | 11.4 | 9.8 | 10.1 | 11.9 | 11.9 |
| Front tyres 4WD | - | 9.5-24 | 11.2-24 | 11.2-24 | 13.6-24 | 13.6-24 | 13.6-24 |
| Rear tyres 4WD | - | 14.9-28 | 16.9-28 | 16.9-30 | 16.9-34 | 16.9-34 | 16.9-34 |
| Weight 4WD | - | 2910 kg | 3175 kg | 3595 kg | 3660 kg | 3965 kg | 3950 kg |
| Diff. lock | - | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs |
