Renault 86-89, 486-489

70Renault89
70Renault88ohjaamo
70Renault89tehot
70Renault89
70Renault88ohjaamo
70Renault89tehot
Manufacturer
Models
Renault 86/486, Renault 88, Renault 89/489
Years
1967-73
Info

At the end of 1967, Renault introduced their new angular models. The successors to the Masters were the slightly smaller 86 and 88, of which the first was once again equipped with an air-cooled MWM engine and the latter with a Renault engine. The engine capacities were smaller than before, and the MWM engine was 3-cylinder. Now the model equipped with the MWM engine became more popular, whereas previously the Renault engine had been the better seller.

The gearbox was a new fully synchronized 8+2. Later, a 12+3 gearbox was also available. The hydraulics featured Tracto Control draft link sensing, and the lifting capacity was increased. The tractors' weights were clearly lower than those of the previous Masters.

In 1969, the lineup was complemented by the 89, equipped with a 60-horsepower water-cooled MWM engine. The headlights became angular, and the grille changed from gray to black in the summer of 1970. The four-wheel-drive models 486 and 489, equipped with a Zetor axle, were introduced at the beginning of 1971. The four-wheel-drive models featured hydrostatic steering. Model 86 was also manufactured in Spain until 1975.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelRenault 86/486Renault 88Renault 89/489
Manufacturer nameRenaultRenaultRenault
Imported to FinlandNoNoNo
Years1967-731967-711969-73
Engine modelMWM D 325-3598MWM D 226-3
Cyl/Turbo/Intercooler343
Displacement2552 cm³2717 cm³3116 cm³
Bore x stroke95×120 mm93×100 mm105×120 mm
Rated power50/2500 hp DIN/rpm51/2500 hp DIN/rpm60/2500 hp DIN/rpm
Torque---
Gears8+212+38+2
Synchronized gears8+212+38+2
Speeds in km/h1,9-24,01,8-25,62,0-24,4
Hydr. flow l/min26 l/min26 l/min26 l/min
Lift controlsmech.mech.mech.
Lift capacity2000 kg2000 kg2000 kg
PTO speeds540/750540/750540/750
Brakesdry discdry discdry disc
Steeringmech./power 4WD hydrost.mech./power 4WD hydrost.mech./power 4WD hydrost.
Turning circle m 2WD6,2 jarrulla6,2 jarrulla6,2 jarrulla
Turning circle m 4WD9,4 jarrulla-9,4 jarrulla
Front tyres 2WD6.50-166.50-166.50-16
Front tyres 4WD9.3-24-9.3-24
Rear tyres 2WD12.4-3212.4-3216.9-28
Rear tyres 4WD16.9-28-16.9-28
Weight 2WD(2250) kg(2265) kg(2440) kg
Weight 4WD(2685) kg-(2775) kg
Height with cab223 cm223 cm223 cm
Length (2WD/4WD)369 cm360 cm369 cm
Wheelbase (2WD/4WD)200/207 cm200 cm200/207 cm
Fuel tank70 l70 l70 l
