Agrifull 80-50 – 80-105

Manufacturer
Models
Agrifull 80-50, Agrifull 80-60, Agrifull 80-75, Agrifull 80-85, Agrifull 80-95, Agrifull 80-105
Years
1980-86
Info

In the Agrifull 80 series introduced in 1980-81, some of the new owner's, Fiat's, technology began to appear. The smallest model, the 80-50, which replaced the Jolly, otherwise matched its predecessor but was equipped with a Fiat engine manufactured by Universal in Romania and Fiat's lifting device. The other models still had VM's air-cooled engine. In those models, the control console was now separated from the engine compartment. Fiat technology included a 12+3 gearbox and oil-bath brakes. The hydraulics were still modest. In the technical specifications, there are, for example, significant differences in dimensions and standard tire sizes between various brochures. At the same time, the range included models 80-46, 80-56, 80-66, and 80-76 equipped with MWM engines, which were sold only on export markets. Based on the 80-50, the Fiat 446 was made, but in the Fiat, the engine was 2.6 liters.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelAgrifull 80-50Agrifull 80-60Agrifull 80-75Agrifull 80-85Agrifull 80-95Agrifull 80-105
Manufacturer nameAgrifullAgrifullAgrifullAgrifullAgrifullAgrifull
Imported to FinlandNoNoNoNoNoNo
Years1981-861980-861980-861980-861980-861980-86
First year sold198119801980198019801980
Last year sold198619861986198619861986
Engine model8035VM 1053 SUVM 1050 NS/SUVM 1050 NS/SUVM 1054 TVM 1056 SU
Cyl/Turbo/Intercooler33444T6
Displacement2339 cm³2856 cm³3456 cm³3808 cm³3808 cm³5712 cm³
Bore x stroke95×110 mm105×110 mm100×110 mm105×110 mm105×110 mm105×110 mm
Rated power hp/rpm DIN48/260058/255078/250085/250097/2400107/2400
Rated power4858788597107
Rated speed260025502500250024002400
Torque Nm/rpm DIN-172/1700---?/1600
Gears9+312+312+312+312+312+3
Synchronized gears-12+312+312+312+312+3
Speeds in km/h2,4-25,01,3-23,11,5-25,61,6-23,11,4-24,91,4-24,9
Hydr. flow l/min-22 l/min---28 l/min
Hydraulic pressure-170 bar---102 bar
Lift controlsmech.mech.mech.mech.mech.mech.
Lift capacity-1325 kg---3200 kg
PTO speeds540/ajo540/ajo540/1000/ajo540/1000540/1000/ajo540/1000/ajo
Brakesdry discwet discwet discwet discwet discwet disc
Steeringmech.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD-----12.8
Front tyres 2WD6.00-167.50-167.50-187.50-187.50-207.50-20
Front tyres 4WD8.00-2011.2R2411.2R2812.4R2812.4R2812.4R28
Rear tyres 2WD13.6R2814.9R3013.6R3813.6R3818.4R3418.4R34
Rear tyres 4WD13.6R2814.9R3013.6R3818.4R3418.4R3418.4R34
Weight 2WD1790 kg2730 kg2950 kg2670 kg3290 kg3500 kg
Weight 4WD1950 kg2970 kg3210 kg2970 kg3650 kg3800 kg
Height with cab-255 cm260 cm258 cm265 cm267 cm
Length (2WD/4WD)360 cm364/382 cm372/400 cm372/400 cm389/416 cm418/445 cm
Wheelbase (2WD/4WD)197/198 cm219/220 cm235/234 cm235/234 cm250/250 cm266/265 cm
Fuel tank-80 l80 l-100 l100 l
Cab noise level-(94) dB----
Creeper gearopt.opt.opt.opt.opt.opt.
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information. There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed. Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
