Fordson Major E27N

Manufacturer
Models
Fordson Major E27N, Fordson Major E27N Diesel
Years
1945-51
Info

The renewed Fordson Major E27N, also known as the "Mörkö-Majori" ("Monster Major"), was introduced in 1945. Its engine was the same 30-year-old side-valve engine as in its predecessor. The petrol version produced 28.5 hp, and the gasoline version 35 hp. Except for the gearbox, the powertrain was renewed. New features included a single-plate clutch, a gear-type reduction hub, and steering brakes. The E27N was painted dark blue with orange rims. Optional equipment included a hydraulic lifting device, headlights, and electric start.

From 1947 onwards, a diesel model equipped with the Perkins P6, producing 45 hp, became available. The diesel model could be identified by the badge on the grille, as seen on the tractor in the picture. The diesel model had much more tractive power than the petrol version, but its price was also nearly twice as high.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelFordson Major E27NFordson Major E27N Diesel
Manufacturer nameFordson MajorFordson Major
Imported to FinlandYesYes
Years1945-511947-51
Cyl/Turbo/Intercooler46
Displacement4380 cm³4727 cm³
Bore x stroke104,8×127 mm88,9×127 mm
Rated power28,5-35,4/1100 hp DIN/rpm45/1500 hp DIN/rpm
Gears3+13+1
Speeds in km/h4,0-14,25,3-18,6
Hydr. flow l/min7.8 l/min8 l/min
Hydraulic pressure100 bar130 bar
Lift controls(mech.)(mech.)
Lift capacity(800) kg(800) kg
PTO speeds540694
Brakesdrum brakesdrum brakes
Steeringmech.mech.
Turning circle m 2WD6.46.4
Front tyres 2WD6.00-196.00-19
Rear tyres 2WD11-3611-36
Weight 2WD(2000) kg(2880) kg
Height with cab(162) cm(167) cm
Length (2WD/4WD)338 cm338 cm
Wheelbase (2WD/4WD)196 cm196 cm
Fuel tank79.5 l79 l
Engine model-P6 (TA)
