MAN AS 325 – AS 542

Manufacturer
Models
MAN AS 325 H/A, MAN AS 325 EH, MAN AS 330 H/A, MAN AS 430 H/A, MAN AS 440 H/A, MAN AS 542 A
Years
1948-55
Info

During the war, about 80% of MAN’s factory buildings were destroyed, but production equipment and spare parts stock were stored in the countryside. A few trucks were built in Nuremberg as early as 1945. Before the war, MAN’s tractor production had focused on large models, but now there was demand rather for smaller tractors. As early as 1941, MAN had introduced a prototype of a 25-horsepower tractor, which was now taken into further development. Familiar solutions ended up on the drawing board, such as a frameless design where the engine is a load-bearing part. Production began in 1948, which was early compared to many competing German brands. The AS 325 H had a 2.7-liter water-cooled, direct-injection four-cylinder diesel engine and a ZF 5-speed transmission. The tractor was well-equipped: it included, among other things, a differential lock, steering brakes, a leaf-sprung front axle, 12-volt electrical system, and a speedometer. The marketing name chosen was Ackerdiesel (=field diesel). The tractor’s color was more turquoise-tinged than the previous green.

At the very beginning, a four-wheel-drive model, the AS 325 A, was also introduced, which was one of the first German four-wheel-drive tractors. Power for the front wheels was taken from the side of the transmission. The front wheels were only slightly larger than on the rear-wheel-drive model.

In 1950, the AS 330 was introduced alongside, with the engine capacity increased to 2.9 liters and power to 30 horsepower. The majority of production was four-wheel-drive models. The AS 330 A is probably the first four-wheel-drive tractor imported to Finland. Cheaper competing brands flooded the market, and MAN did not achieve a very high market share with rear-wheel-drive tractors.

In 1952, the AS 430 was introduced, featuring a 6-speed transmission and more powerful brakes, as well as the AS 440, where the engine speed was increased from 1500 to 2000 rpm. Power rose to 40 horsepower. An optional lowering crawler gear was available, which also allowed the power take-off speed to be reduced from 735 to 550. The same engine, enhanced by another 2 horsepower, was installed in larger frames in the AS 542 model. It also had a sturdier transmission and rear axle.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelMAN AS 325 H/AMAN AS 325 EHMAN AS 330 H/AMAN AS 430 H/AMAN AS 440 H/AMAN AS 542 A
Manufacturer nameMANMANMANMANMANMAN
Imported to FinlandNoNoYesNoNoNo
Years1948-521952-551950-551952-541952-551953-55
Engine modelD 8814 GSD 8814 fD 9214 fD 9214 fD 9214 zD 9214 G2
Cyl/Turbo/Intercooler444444
Displacement2676 cm³2676 cm³2930 cm³2930 cm³2930 cm³2930 cm³
Bore x stroke88×110 mm88×110 mm92×110 mm92×110 mm92×110 mm92×110 mm
Rated power25/1500 hp DIN/rpm25/1500 hp DIN/rpm30/1500 hp DIN/rpm30/1500 hp DIN/rpm40/2000 hp DIN/rpm42/2000 hp DIN/rpm
Torque------
Gears5+15+15+16+16+1/12+25+1/10+2
Speeds in km/h3,5-20,03,4-19,33,5-20,01,9-20,02,6-27,03,6-27,1
Lift controlsmech.mech.mech.mech.mech.mech.
PTO speeds540550540550550/735550/735
Brakesdrum brakesdrum brakesdrum brakesdrum brakesdrum brakesdrum brakes
Steeringmech.mech.mech.mech.mech.mech.
Front tyres 2WD6.00-165.50-166.50-166.50-206.50-20-
Front tyres 4WD6.50-20-6.50-206.50-206.50-206.50-20
Rear tyres 2WD9-2410-2810-2810-2810-28-
Rear tyres 4WD9-24-10-2810-2810-2813-30
Weight 2WD(1760) kg(1800) kg(1800) kg(1870) kg(1870) kg-
Weight 4WD(1920) kg-(1900) kg(2000) kg(2000) kg(2450) kg
Height with cab(170) cm(170) cm(170) cm(170) cm(170) cm(180) cm
Length (2WD/4WD)294/302 cm305 cm302/302 cm313/313 cm313/313 cm350 cm
Wheelbase (2WD/4WD)182/182 cm182 cm182/182 cm182/182 cm182/182 cm213 cm
Fuel tank50/40 l42 l40 l-42 l60 l
Creeper gearopt.opt.opt.opt.opt.opt.
Turning circle m 2WD-5,0 jarrulla5,0 jarrulla5,0 jarrulla5,0 jarrulla-
Turning circle m 4WD--6,0 jarrulla6,0 jarrulla6,0 jarrulla7,0 jarrulla
Powershift gears-----/mech.-/mech.
Hydr. flow l/min----16 l/min16 l/min
Hydraulic pressure----130 bar130 bar
Lift capacity-----1300 kg
