Massey Ferguson 8650-8690

09MF8600
09MF8600ohjaamo
09MF8690tehot
09MF8600
09MF8600ohjaamo
09MF8690tehot
Manufacturer
Models
Massey Ferguson 8650, Massey Ferguson 8660, Massey Ferguson 8670, Massey Ferguson 8680, Massey Ferguson 8690
Years
2008-11
Info

In the autumn of 2008, the MF 8400 series was updated to the 8600 series. In marketing, the main focus was on the largest model of the range, the 8690, which at that time was the most powerful fixed-frame tractor on the market. The maximum power of the 8690 was 370 hp.

The engines of all models were 8.4 liters. In fact, the smallest model, the 8650, had similar power output to the third smallest model of the previous series, the 8470. The 8690 featured a new SCR system, i.e., urea injection, which was intended to reduce fuel consumption despite emission limits. The AdBlue tank was filled approximately every other refueling. The stepless Dyna VT transmission included the Dynamic Tractor Management system, which corresponded to Fendt's TMS. The transmission control, however, differed from Fendt's. Driving speed could be adjusted with the lever on the left side, the joystick on the armrest, or the speed pedal.

Hydraulic flow was increased to 175 liters per minute and lifting capacity to 12 tons. The front axle was the new Dana 770 series. As an option, there was SpeedSteer, which allowed the steering to be adjusted to be faster than normal at speeds under 18 km/h.

The four-post cab was new and 28% more spacious than before. The interior color was changed to light beige. Most of the controls were centralized on the armrest. Cab suspension was standard, while front axle suspension was only available on the 50 km/h version. In Finland, the OptiRide Plus cab suspension—adjusting based on acceleration sensor measurements—and heated mirrors were standard features.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelMassey Ferguson 8650Massey Ferguson 8660Massey Ferguson 8670Massey Ferguson 8680Massey Ferguson 8690
Manufacturer nameMassey FergusonMassey FergusonMassey FergusonMassey FergusonMassey Ferguson
Imported to FinlandYesYesYesYesYes
Years2008-112008-112008-112008-112008-11
Engine model84CTA-4V84CTA-4V84CTA-4V84CTA-4V84CTA-4V SCR
Cyl/Turbo/Intercooler6TI6TI6TI6TI6TI
Displacement8400 cm³8400 cm³8400 cm³8400 cm³8400 cm³
Bore x stroke111×145 mm111×145 mm111×145 mm111×145 mm111×145 mm
Rated power-----
Max power-----
Torque-----
Gearssteplesssteplesssteplesssteplessstepless
Synchronized gearssteplesssteplesssteplesssteplessstepless
Powershift gearssteplesssteplesssteplesssteplessstepless
Reverserhydr.hydr.hydr.hydr.hydr.
Speeds in km/h0,03-43/530,03-43/530,03-43/530,03-43/530,03-43/53
Max. speed 43/53 km/h43/53 km/h43/53 km/h43/53 km/h43/53 km/h
Hydr. flow l/min175 l/min175 l/min175 l/min175 l/min175 l/min
Hydraulic pressure200 bar200 bar200 bar200 bar200 bar
Lift controlselec.elec.elec.elec.elec.
Lift capacity12000 kg12000 kg12000 kg12000 kg12000 kg
PTO speeds540/1000540/1000540/1000540/1000540/1000
Brakeswet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD11.511.511.511.511.5
Front tyres 4WD600/70R28600/70R28600/70R28620/65R34620/65R34
Rear tyres 4WD650/85R38650/85R38650/85R38710/75R42710/75R42
Weight 4WD10300 kg10300 kg10300 kg10300 kg10300 kg
Height with cab338 cm338 cm338 cm338 cm338 cm
Length (2WD/4WD)567 cm567 cm567 cm567 cm567 cm
Wheelbase (2WD/4WD)310 cm310 cm310 cm310 cm310 cm
Fuel tank690 l690 l690 l690 l590(+AB30) l
Cab noise level70 dB70 dB70 dB70 dB70 dB
Solid cabxxxxx
Diff. lockdisc lockdisc lockdisc lockdisc lockdisc lock
Autom. differential locksxxxxx
Air suspension seatxxxxx
Air conditioningautom.autom.autom.autom.autom.
Trip computerxxxxx
Creeper gearxxxxx
