Steyr 8045-8085 RS 2 / Marshall S-542 – S-744

89Steyr8085
89Steyr8065ohjaamo
89MarshallS744
89Steyr8085
89Steyr8065ohjaamo
89MarshallS744
Manufacturer
Models
Steyr 8045, Steyr 8055, Steyr 8055 T, Steyr 8065, Marshall S-542/544, Steyr 8075, Marshall S-642/644, Steyr 8085, Marshall S-744
Years
1988-93
Info

In 1988, the Steyr small series was updated. The RS 2 lineup featured a new cab with a side gear lever. The interior of the cab was still very much metal, and the series was not offered in countries where noise levels below 85 dB were required. Special models for viticulture and vegetable cultivation were also available.

New model options included the 8045 (42 hp) and the 8085 (72 hp). Additionally, the 8055 Turbo equipped with the 8065's engine was offered, which was smaller in external dimensions than its bigger brother. In the vegetable cultivation lineup, in addition to these models, there was the 8095, which had an 80-horsepower turbo engine. The transmission featured a mechanical quick shift as standard, except for the smallest model. Both 30 km/h and 40 km/h versions were available.

After Marshall ended its own tractor production in 1989, it planned its future based on models from IMT and Torpedo, among others, but ultimately took Steyr models for its sales. The only difference from Steyr was the yellow-black color scheme.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelSteyr 8045Steyr 8055Steyr 8055 TSteyr 8065Marshall S-542/544Steyr 8075Marshall S-642/644Steyr 8085Marshall S-744
Manufacturer nameSteyrSteyrSteyr------
Imported to FinlandNoNoNoNoNoNoNoNoNo
Years1988-921988-921988-921988-921988-921988-931988-931988-931988-93
Engine modelWD308.48WD311.47WD311.85WD311.85WD311.85WD411.46WD411.46WD411.44WD411.44
Cyl/Turbo/Intercooler333T3T3T444T4T
Displacement2356 cm³2592 cm³2592 cm³2592 cm³2592 cm³3456 cm³3456 cm³3456 cm³3456 cm³
Bore x stroke100×100 mm100×110 mm100×110 mm100×110 mm100×110 mm100×110 mm100×110 mm100×110 mm100×110 mm
Rated power42/2400 hp DIN/rpm48/2400 hp DIN/rpm56/2400 hp DIN/rpm56/2400 hp DIN/rpm56/2400 hp DIN/rpm64/2400 hp DIN/rpm64/2400 hp DIN/rpm72/2100 hp DIN/rpm72/2100 hp DIN/rpm
Torque---------
Gears8+416+816+816+816+816+816+816+816+8
Synchronized gears8+416+816+816+816+816+816+816+816+8
Reversermech.mech.mech.mech.mech.mech.mech.mech.mech.
Max. speed 30 km/h30/40 km/h30/40 km/h30/40 km/h30/40 km/h30/40 km/h30/40 km/h30/40 km/h30/40 km/h
Hydr. flow l/min34 l/min29 l/min29 l/min42 l/min42 l/min42 l/min42 l/min39 l/min39 l/min
Lift controlsmech.mech.mech.mech.mech.mech.mech.mech.mech.
Lift capacity2200 kg2200 kg2200 kg2600 kg2600 kg2600 kg2600 kg2600 kg2600 kg
PTO speeds540/1000540/1000540/1000540/1000540/1000540/1000540/1000540/1000540/1000
Brakesdrum brakesdrum brakesdrum brakesdrum brakesdrum brakesdrum brakesdrum brakesdrum brakesdrum brakes
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 2WD6.96.8-6.96.97.37.3--
Turning circle m 4WD7.47.27.27.57.59.19.19.19.1
Front tyres 2WD6.50-167.50-16-7.50-167.50-167.50-187.50-18--
Front tyres 4WD10.5-1810.5-2010.5-2010.5-2010.5-2011.2-2411.2-2412.5-2012.5-20
Rear tyres 2WD12.4-3212.4-32-12.4-3212.4-3213.6-3613.6-36--
Rear tyres 4WD12.4-3212.4-3212.4-3212.4-3212.4-3213.6-3613.6-3614.9-3014.9-30
Weight 2WD1900 kg2200 kg-2370 kg2370 kg2470 kg2470 kg--
Weight 4WD2060 kg2430 kg2480 kg2660 kg2660 kg2840 kg2840 kg2900 kg2900 kg
Height with cab219 cm216 cm216 cm225 cm225 cm231 cm231 cm227 cm227 cm
Length (2WD/4WD)317/325 cm319/329 cm329 cm350 cm350 cm361/370 cm361/370 cm368 cm368 cm
Wheelbase (2WD/4WD)190/198 cm190/193 cm193 cm199/203 cm199/203 cm212/215 cm212/215 cm215 cm215 cm
Fuel tank53 l60 l60 l60 l60 l60 l60 l60 l60 l
Cab noise level85 dB88.5 dB88.5 dB86 dB86 dB88.5 dB88.5 dB87 dB87 dB
Solid cabopt.opt.opt.xxxxxx
Diff. lockopt.opt.opt.opt.opt.opt.opt.opt.opt.
Creeper gearopt.opt.opt.opt.opt.opt.opt.opt.opt.
Powershift gears-mech.mech.mech.mech.mech.mech.mech.mech.
Speeds in km/h---2,2-33,82,2-33,82,4-37,22,4-37,22,4-37,22,4-37,2
