Valmet Mega 8300-8850

90Valmet8300
90Valmet8300ohjaamo
90Valmet8300
90Valmet8300ohjaamo
Manufacturer
Models
Valmet 8300, Valmet 8600, Valmet 8800, Valmet 8850
Years
1990-98
Info

There had been a clear gap in Valmet's offerings in the larger class for a couple of years, since after the discontinuation of the Volvo BM-based models 2005 and 2105, the largest model had been the 905. Massey Ferguson chose Valmet as the engine supplier for their largest models, which led to a solution where MF manufactured tractors based on their 3600 series for Valmet.

The Valmet Mega 8300 and 8600 were introduced at the end of 1989. For the first time, they featured a hood and grille designed according to Valmet’s new styling line. The color was always white (although red versions were made later). The cab was also modified, especially in terms of color, to fit Valmet’s line-up. Unlike MF, the dashboard was black. The control panel for the electric lift was changed to match Valmet’s Autocontrol system, which meant that, for example, the raise-lower switch no longer had a stop position.

The MF-based Mega came in two models. The 8300 (140 hp) was naturally aspirated and the 8600 (170 hp) was turbocharged. Both had Valmet’s 7.4-liter engine. There were small technical differences compared to the MF models. The slowest speed of the 8600’s gearbox was unusually high. Apparently, for some reason, the gear ratios were modified to speed up the 30 km/h version to run at 40 km/h. Valmet claimed a tighter turning radius than MF but a higher noise level.

During the years 1992-93, the 8300T was offered, with an output of 155 hp. From 1994 to 1996, the 8800 model was manufactured, where the power was raised from the 8600’s 170 horsepower to 190. Compared to before, the number of gears was now doubled thanks to MF’s 4-speed powershift marketed under the name Dynashift. The clutch was a wet multi-plate clutch.

In 1997, the short-lived MF 8160 parallel model, the Valmet 8850 (200 hp), replaced the 8800. It featured the new cab from the MF 8100 series. The 8850’s rounded front was very different in appearance from previous models, as it came from Steyr, which sold the same tractor under the name Steyr 9200. The Valmet 8850 was available in red and white. The 8850 was sold only in France.

The Mega 8300/8600/8800 was a makeshift solution made with little effort, which was displaced as Valmet’s own larger models were introduced to the market.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelValmet 8300Valmet 8600Valmet 8800Valmet 8850
Manufacturer nameValmetValmetValmetValmet
Imported to FinlandYesYesNoNo
Years1990-921990-941994-961997-98
Engine model612D612DS634DS634DS
Cyl/Turbo/Intercooler66T6T6T
Displacement7368 cm³7368 cm³7368 cm³7368 cm³
Bore x stroke108×134 mm108×134 mm108×134 mm108×134 mm
Rated power140/2200 hp DIN/rpm170/2200 hp DIN/rpm190/2200 hp DIN/rpm200/2200 hp DIN/rpm
Torque----
Gears16+1616+1632+3232+32
Synchronized gears16+1616+1632+3232+32
Powershift gearshydr.hydr.4-step4-step
Reversermech.mech.mech.mech.
Speeds in km/h2,9-38,44,1-36,92,5-39,7-
Max. speed 40 km/h40 km/h40 km/h40 km/h
Hydr. flow l/min60 l/min60 l/min54 l/min110 l/min
Hydraulic pressure185 bar185 bar185 bar180 bar
Lift controlselec.elec.elec.elec.
Lift capacity7800 kg7800 kg7800 kg7800 kg
PTO speeds540/1000540/100010001000
Brakeswet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD10.410.410.411.3
Front tyres 4WD16.9R2816.9R2816.9R3016.9R30
Rear tyres 4WD20.8R3820.8R3820.8R4220.8R42
Weight 4WD5980 kg6020 kg6500 kg7560 kg
Height with cab290 cm290 cm298 cm302 cm
Length (2WD/4WD)559 cm559 cm560 cm547 cm
Wheelbase (2WD/4WD)293 cm293 cm293 cm293 cm
Fuel tank250 l250 l250 l270 l
Cab noise level79 dB77 dB76 dB74 dB
Solid cabxxxx
Diff. lockdifferential lock with cogsdifferential lock with cogsdifferential lock with cogsdifferential lock with cogs
Autom. differential locksxxxx
Air conditioningxxxx
