Valmet Mega 8400

96Valmet8400
96Valmet8400ohjaamo
96Valmet8400
96Valmet8400ohjaamo
Manufacturer
Models
Valmet 8400, Valmet 8400, Valmet 8400
Years
1996-2000
Info

From the Mega 8000 series, the favorite became the 8400, which was especially popular as a contract machine. After the introduction of the 8050 series, the 8400 was kept in production but received a few updates. The lifting capacity was increased to 7 tons. However, the engine represented an older generation compared to the equally powerful 8450. Autocontrol was updated to version 2.1, which included a so-called forced descent function. One of the secrets to the 8400’s popularity was the traffic tractor version, which with its 50 km/h speed, competitors still could not offer in the mid-1990s.

In the spring of 2000, the engine was replaced with a newer version. Power increased to 150 horsepower, partly thanks to new nozzles, and torque rose by as much as 105 Nm. The torque increase was 31% instead of the previous 16%. Standard equipment now included, among other things, a sturdier industrial front axle, larger tires, and longer lift arms.

In the spring of 2002, power was further increased to 160 horsepower and standard equipment included millimeter tires. The engine now featured a viscous fan. The 8400 was also available as a long wheelbase version. The 8400 was only discontinued after the introduction of the T Classic models.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelValmet 8400Valmet 8400Valmet 8400
Manufacturer nameValmetValmetValmet
Imported to FinlandYesYesYes
Years1996-20002000-022002-04
Engine model620DS620DS620DSIE
Cyl/Turbo/Intercooler6T6T6T
Displacement6598 cm³6598 cm³6598 cm³
Bore x stroke108×120 mm108×120 mm108×120 mm
Rated power140/2200 hp DIN/rpm150/2200 hp DIN/rpm160/2200 hp DIN/rpm
Torque---
Gears36+3636+3636+36
Synchronized gears36+3636+3636+36
Powershift gears3-step3-step3-step
Reversermech.mech.mech.
Speeds in km/h0,6-39,2/47,80,6-39,2/47,80,6-39,2/47,8
Max. speed 40 (50) km/h40 (50) km/h40 (50) km/h
Hydr. flow l/min73 l/min73 l/min73 l/min
Lift controlselec.elec.elec.
Lift capacity7000 kg6700 kg6700 kg
PTO speeds540/1000/ajo540/1000/ajo540/1000/ajo
Brakeswet discwet discwet disc
Steeringhydrost.hydrost.hydrost.
Turning circle m 4WD10.210.210.2
Front tyres 4WD14.9R2816.9R28480/70R28
Rear tyres 4WD18.4R3820.8R38580/70R38
Weight 4WD4870 kg5080 kg5080 kg
Height with cab280 cm281 cm284 cm
Length (2WD/4WD)475 cm485 cm485 cm
Wheelbase (2WD/4WD)256 cm256 cm256 (275) cm
Fuel tank165 l165 l165 l
Cab noise level78 dB77 dB74.5 dB
Solid cabxxx
Diff. lockdisc lockdisc lockdisc lock
Autom. differential locksxxx
