Valtra T121-T191

07ValtraTohjaamo
07ValtraT
07ValtraTohjaamo
07ValtraT
Manufacturer
Models
Valtra T121, Valtra T131, Valtra T151e, Valtra T161, Valtra T171, Valtra T191
Years
2007-12
Info

At the beginning of 2007, the improvements introduced in the N series were applied to the T series, and the entire model range transitioned to common rail engines. The last digit of the model designation was updated from zero to 1. The 6-cylinder CTA engines from SisuDiesel featured four-valve cylinder heads. The engines had a boost power function, which was available at road speeds; in addition to the T191, it was also available in the mid-range of the range gearbox and in the crawling gear range. The maximum power of the T191 was obtained, as before, when at least 400 Nm of torque was transmitted through the power take-off. The Eco model was now the T151e and, in addition to the Eco function, a Power program was selectable.

The T series now had three equipment levels: Classic, HiTech, and Advance. The Classic did not have the boost power function or electrically controlled transmission, and the direction changer was mechanical. The Advance had a 115 l/min variable displacement pump in the hydraulics and electrically controlled valves, as well as a control armrest. As standard, it also included a recording-programmable headland automation. The cab was the same as the N series and the mudguards were new.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelValtra T121Valtra T131Valtra T151eValtra T161Valtra T171Valtra T191
Manufacturer nameValtraValtraValtraValtraValtraValtra
Imported to FinlandNoYesYesYesYesYes
Years2007-112007-112007-112007-112007-122007-12
Engine model66CTA66CTA66CTA66CTA74CTA74CTA
Cyl/Turbo/Intercooler6TI6TI6TI6TI6TI6TI
Displacement6598 cm³6598 cm³6598 cm³6598 cm³7368 cm³7368 cm³
Bore x stroke108×120 mm108×120 mm108×120 mm108×120 mm108×134 mm108×134 mm
Rated power------
Max power------
Torque------
Gears36+3636+3636+3636+3636+3636+36
Synchronized gears36+3636+3636+3636+3636+3636+36
Powershift gears3-step3-step3-step3-step3-step3-step
Reverserhydr.hydr. (Cl: mech.)hydr.hydr. (Cl: mech.)hydr. (Cl: mech.)hydr.
Speeds in km/h0,6-38,5/48,30,6-38,5/48,30,6-41,90,6-40,8/51,20,6-40,8/51,20,6-40,8/51,2
Max. speed 40 (50) km/h40 (50) km/h40 km/h40 (50) km/h40 (50) km/h40 (50) km/h
Hydr. flow l/min73 l/min73, Adv. 115 l/min73, Adv. 115 l/min73, Adv. 115 l/min73, Adv. 115 l/min73, Adv. 115 l/min
Hydraulic pressure196 bar196, Adv. 205 bar196, Adv. 205 bar196, Adv. 205 bar196, Adv. 205 bar196, Adv. 205 bar
Lift controlselec.elec.elec.elec.elec.elec.
Lift capacity7700 kg7700, Adv. 8100 kg7700, Adv. 8100 kg7700, Adv. 8100 kg7700, Adv. 8100 kg7700, Adv. 8100 kg
PTO speeds540/1000540/1000750/1000540/1000540/1000750/1000
Brakeswet discwet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD11.211.211.211.211.211.2
Front tyres 4WD16.9R2816.9R2816.9R3016.9R3016.9R3016.9R30
Rear tyres 4WD20.8R3820.8R3820.8R4220.8R4220.8R4220.8R42
Weight 4WD5650 kg5650 kg5950 kg5950 kg5950 kg5950 kg
Height with cab300 cm300 cm305 cm305 cm305 cm305 cm
Length (2WD/4WD)515 cm515 cm515 cm515 cm515 cm515 cm
Wheelbase (2WD/4WD)275 cm275 cm275 cm275 cm275 cm275 cm
Fuel tank165 (335) l165 (335) l165 (335) l165 (335) l165 (335) l165 (335) l
Cab noise level71 dB71 (C. 71,5) dB71 dB71 (C. 71,5) dB71 (C. 71,5) dB71 dB
Solid cabxxxxxx
Diff. lockfriction lockfriction lockdisc lockdisc lockdisc lockdisc lock
Autom. differential locksxxxxxx
Air suspension seatxxxxxx
Air conditioningxxxxxx
