Zetor Forterra 8641-11741

04Zetor11441
04Zetor11411ohjaamo
04Zetor11441nopeudet
04Zetor11441
04Zetor11411ohjaamo
04Zetor11441nopeudet
Manufacturer
Models
Zetor Forterra 8641, Zetor Forterra 9641, Zetor Forterra 10641, Zetor Forterra 11441, Zetor Forterra 11741
Years
2002-07
Info

The exterior design of the Forterra model line introduced in 1999 was streamlined in 2002. The engine specifications were slightly improved. The new model was the 110-horsepower 11441. The engine oil change interval was still only 200 hours. The hydraulic output was increased to 70 liters per minute and the lifting capacity to 5800 kilograms. The electric lift device was now standard. There are significant differences in the stated measurements and weight data between different countries. The information listed here should be without front weights or front lift equipment.

The updated Forterras came to Finland only in the summer of 2004, brought by the new importer, Zetra Oy.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelZetor Forterra 8641Zetor Forterra 9641Zetor Forterra 10641Zetor Forterra 11441Zetor Forterra 11741
Manufacturer nameZetor ForterraZetor ForterraZetor ForterraZetor ForterraZetor Forterra
Imported to FinlandNoYesYesYesNo
Years2002-072002-072002-072002-072002-07
Engine model12031003130314031006.6WT
Cyl/Turbo/Intercooler4T4T4TI4TI6T
Displacement4156 cm³4156 cm³4156 cm³4156 cm³6000 cm³
Bore x stroke105×120 mm105×120 mm105×120 mm105×120 mm105×115,5 mm
Rated power80/2200 hp DIN/rpm90/2200 hp DIN/rpm101/2200 hp DIN/rpm110/2200 hp DIN/rpm120/2350 hp DIN/rpm
Torque-----
Gears24+1824+1824+1824+1824+18
Synchronized gears24+1824+1824+1824+1824+18
Powershift gears3-step3-step3-step3-step3-step
Reversermech.mech.mech.mech.mech.
Speeds in km/h1,9-401,9-401,9-401,9-401,9-40
Max. speed 43 km/h43 km/h43 km/h43 km/h44 km/h
Hydr. flow l/min70 (60) l/min70 (60) l/min70 l/min70 l/min70 l/min
Hydraulic pressure180 bar180 bar180 bar180 bar180 bar
Lift controlselec.elec.elec.elec.elec.
Lift capacity5850 kg5850 kg5850 kg5850 kg5850 kg
PTO speeds540/1000/ajo540/1000/ajo540/1000/ajo540/1000/ajo540/1000/ajo
Brakeswet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD9.69.69.69.610.2
Front tyres 4WD12.4-2812.4-2812.4-2812.4-2814.9R24
Rear tyres 4WD16.9R3816.9R3816.9R3816.9R3818.4R38
Weight 4WD4576 kg4576 kg4590 kg4590 kg4900 kg
Height with cab278 cm278 cm278 cm278 cm281 cm
Length (2WD/4WD)467 cm467 cm467 cm467 cm496 cm
Wheelbase (2WD/4WD)239 cm239 cm239 cm239 cm266 cm
Fuel tank180 l180 l180 l180 l180 l
Cab noise level81 dB81 dB81 dB81 dB79 dB
Solid cabxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lock
Creeper gearopt.opt.opt.opt.opt.
