Zetor Proxima HS 80-120

Manufacturer
Models
Zetor Proxima HS 80, Zetor Proxima HS 100, Zetor Proxima HS 110, Zetor Proxima HS 120, Zetor Proxima HS 80, Zetor Proxima HS 90, Zetor Proxima HS 100, Zetor Proxima HS 110, Zetor Proxima HS 120
Years
2017-
Info

The most advanced version of the Zetor Proxima series in that year was the HS, equipped with a 3-speed quick gear and a hydraulic direction reverser. The engines were 4.2-liter inline-fours fitted with mechanical injection pumps. However, a particulate filter and exhaust gas recirculation were included as standard equipment. Both Stage IIIb and IV versions were available, the latter featuring urea injection. The wheelbase was just over 10 cm longer than other Proxima models. In Finland, the standard features included an electric three-point hitch, 60 l/min hydraulics, a push-button clutch, an air-suspended seat, and an air conditioning system.

For the year 2020, the design was modernized and the heating system was enhanced.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelZetor Proxima HS 80Zetor Proxima HS 100Zetor Proxima HS 110Zetor Proxima HS 120Zetor Proxima HS 80Zetor Proxima HS 90Zetor Proxima HS 100Zetor Proxima HS 110Zetor Proxima HS 120
Manufacturer nameZetor ProximaZetor ProximaZetor ProximaZetor ProximaZetor ProximaZetor ProximaZetor ProximaZetor ProximaZetor Proxima
Imported to FinlandNoNoNoYesNoNoNoNoYes
Years2017-202017-202017-202017-202020-2020-2020-2020-2020-
Engine model11061006/10171306/13171406/141711061206101713171417
Cyl/Turbo/Intercooler4TI4TI4TI4TI4TI4TI4TI4TI4TI
Displacement4156 cm³4156 cm³4156 cm³4156 cm³4156 cm³4156 cm³4156 cm³4156 cm³4156 cm³
Bore x stroke105×120 mm105×120 mm105×120 mm105×120 mm105×120 mm105×120 mm105×120 mm105×120 mm105×120 mm
Rated power---------
Torque---------
Gears24+2424+2424+2424+2424+2424+2424+2424+2424+24
Synchronized gears24+2424+2424+2424+2424+2424+2424+2424+2424+24
Powershift gears3-step3-step3-step3-step3-step3-step3-step3-step3-step
Reverserhydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.
Speeds in km/h2,0-36,02,0-36,02,0-36,02,0-36,02,0-36,02,0-36,02,0-36,02,0-36,02,0-36,0
Max. speed 40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h
Hydr. flow l/min50 (60) l/min50 (60) l/min50 (60) l/min50 (60) l/min50 (60) l/min50 (60) l/min50 (60) l/min50 (60) l/min50 (60) l/min
Hydraulic pressure190 bar190 bar190 bar190 bar190 bar190 bar190 bar190 bar190 bar
Lift controlsmech./elec.mech./elec.mech./elec.mech./elec.mech./elec.mech./elec.mech./elec.mech./elec.mech./elec.
Lift capacity3970 kg3970 kg3970 kg3970 kg3970 kg3970 kg3970 kg3970 kg3970 kg
PTO speeds540/1000/ajo540/1000/ajo540/1000/ajo540/1000/ajo540/1000/ajo540/1000/ajo540/1000/ajo540/1000/ajo540/1000/ajo
Brakeswet discwet discwet discwet discwet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD11.411.411.411.411.411.411.411.411.4
Front tyres 4WD13.6R2413.6R2413.6R2413.6R2413.6R2413.6R2413.6R2413.6R2413.6R24
Rear tyres 4WD16.9R3416.9R3416.9R3416.9R3416.9R3416.9R3416.9R3416.9R3416.9R34
Weight 4WD4260 kg4260 kg4260 kg4260 kg4550 kg4550 kg4550 kg4550 kg4550 kg
Height with cab285 cm285 cm285 cm285 cm290 cm290 cm290 cm290 cm290 cm
Length (2WD/4WD)407 cm407 cm407 cm407 cm407 cm407 cm407 cm407 cm407 cm
Wheelbase (2WD/4WD)244 cm244 cm244 cm244 cm244 cm244 cm244 cm244 cm244 cm
Fuel tank190 l190 l190 l190 l190 l190 l190+AB25 l190+AB25 l190+AB25 l
Cab noise level76 dB76 dB76 dB76 dB76 dB76 dB76 dB76 dB76 dB
Solid cabxxxxxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lock
