Siirry sivupalkkiinSiirry alaosaanWhite 100-185






Texas Instruments sold White Farm Equipment’s tractor production to Allied Products, a company that owned the agricultural machinery manufacturer New Idea. The combines ended up with MF (Massey Ferguson). The White-New Idea tractor brand returned from WFE to White in 1987. In 1987, the main tractor lineup was renewed, and the model designations became White 100, 120, 140, 160, and 185. The designations roughly indicated the power take-off horsepower. The engines were changed to Cummins. The transmission continued to be the age-old unsynchronized 18+6, which had a 3-speed hydraulic powershift. Lifting capacity was increased. Even the smaller models now had oil-immersed disc brakes. The 100-140 four-wheel-drive models had a significantly longer wheelbase than before and featured a limited-slip differential for the first time. The middle model was now based on the technology of the smaller models, unlike before. Only the 160 had a larger engine and a dual-disc clutch. The cab was similar to the previous one: quiet but simple. As an optional extra, the FieldFacts multifunction display could be equipped with a wheel slip monitor.
This is an automated translation. Please report any issues in the translation.
| Model | White 100 | White 120 | White 140 | White 160 | White 185 |
|---|---|---|---|---|---|
| Manufacturer name | White | White | White | White | White |
| Imported to Finland | No | No | No | No | No |
| Years | 1987-90 | 1987-90 | 1987-90 | 1987-90 | 1987-90 |
| Engine model | B6-590 | B6-590 | B6-590 | C6T-830 | C6T-830 |
| Cyl/Turbo/Intercooler | 6 | 6T | 6TA | 6T | 6TA |
| Displacement | 5883 cm³ | 5883 cm³ | 5883 cm³ | 8277 cm³ | 8277 cm³ |
| Bore x stroke | 102×120 mm | 98,4×127 mm | 98,4×127 mm | 114×135,1 mm | 114×135,1 mm |
| Rated power | - | - | - | - | - |
| Gears | 18+6 | 18+6 | 18+6 | 18+6 | 18+6 |
| Powershift gears | 3-step | 3-step | 3-step | 3-step | 3-step |
| Speeds in km/h | 2,4-28,2 | 2,6-30,2 | 2,8-29,3 | 2,9-29,3 | 2,9-29,3 |
| Hydr. flow l/min | 71.9 l/min | 83.3 l/min | 83.3 l/min | 83.3 l/min | 83.3 l/min |
| Hydraulic pressure | 155 bar | 155 bar | 155 bar | 158 bar | 158 bar |
| Lift controls | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 3261 kg | 3261 kg | 3261 kg | 3191 kg | 3191 kg |
| PTO speeds | 540/1000 | 540/1000 | 540/1000 | 1000 | 1000 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 2WD | 7,16 jarruilla | 7,16 jarruilla | 8,46 jarruilla | 7,92 jarrulla | 7,92 jarrulla |
| Turning circle m 4WD | 7,78 jarruilla | 7,78 jarruilla | 8,92 jarruilla | 8,98 jarrulla | 8,98 jarrulla |
| Front tyres 2WD | 9.5L15 | 10.00-16 | 11.00-16 | 11.00-16 | 14L-16 |
| Front tyres 4WD | 14.9-28 | 14.9-28 | 14.9-28 | 14.9-30 | 14.9-30 |
| Rear tyres 2WD | 18.4R38 | 18.4R38 | 18.4R38 | 20.8R38 | 20.8R38 |
| Rear tyres 4WD | 18.4R38 | 18.4R38 | 18.4R38 | 20.8R38 | 20.8R38 |
| Weight 2WD | 5400 kg | 5512 kg | 5625 kg | 5985 kg | 6120 kg |
| Weight 4WD | 5895 kg | 6007 kg | 6210 kg | 6660 kg | 6795 kg |
| Height with cab | 298/300 cm | 298/300 cm | 302/307 cm | 305/310 cm | 305/310 cm |
| Length (2WD/4WD) | 441/440 cm | 441/440 cm | 446 cm | 427 cm | 427 cm |
| Wheelbase (2WD/4WD) | 283/250 cm | 283/250 cm | 283/250 cm | 284/229 cm | 284/229 cm |
| Fuel tank | 220 l | 220 l | 243 l | 281 l | 281 l |
| Cab noise level | 77 dB | 77 dB | 75.5 dB | 76.5 dB | 76.5 dB |
| Solid cab | x | x | x | x | x |
| Diff. lock | friction lock | friction lock | friction lock | friction lock | friction lock |
| Air conditioning | x | x | x | x | x |
