Same Virtus 115 – 135 / Lamborghini Spark R 115 – 135

Manufacturer
Models
Same Virtus 115, Lamborghini Spark R 115, Same Virtus 125, Lamborghini Spark R 125, Same Virtus 135, Lamborghini Spark  R 135, Same Virtus 115 RVShift, Lamborghini Spark R 115 RVShift, Same Virtus 125 RVShift, Lamborghini Spark R 125 RVShift, Same Virtus 135 RVShift, Lamborghini Spark R 135 RVShift, Lamborghini Spark R 115 VRT, Lamborghini Spark R 125 VRT, Lamborghini Spark R 135 VRT
Years
2022-
Info

At the beginning of 2022, the Virtus and Spark models were introduced; apart from the engine, they corresponded to Deutz-Fahr’s 6C series. Same and Lamborghini branded models used 3.8-litre FARMotion engines. The two larger versions featured a variable-geometry turbocharger. The 30+30-speed Powershift gearbox included a 3-speed quick shift and a mechanical main shift lever. The new RVShift was a 20+16-speed full Powershift transmission, allowing a top speed of 50 km/h at 1,910 rpm. If desired, you could shift up three ratios in one move. The Lamborghini was also available with a stepless VRT transmission, which offered separate field and road ranges.

In the hydraulics, the basic version had an open-center system with a 90 l/min pump (the “115” model had a 55 l/min pump) and mechanical valves. In the load-sensing version, pump output was 120 l/min and the valves were either mechanical or electronic. Lift capacity was 5,000 kg, or 7,000 kg with additional rams. Cab noise level was specified at 71 dB. As an option, the cab could be fitted with either mechanical or pneumatic suspension.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelSame Virtus 115Lamborghini Spark R 115Same Virtus 125Lamborghini Spark R 125Same Virtus 135Lamborghini Spark  R 135Same Virtus 115 RVShiftLamborghini Spark R 115 RVShiftSame Virtus 125 RVShiftLamborghini Spark R 125 RVShiftSame Virtus 135 RVShiftLamborghini Spark R 135 RVShiftLamborghini Spark R 115 VRTLamborghini Spark R 125 VRTLamborghini Spark R 135 VRT
Imported to FinlandNoNoNoNoNoNoNoNoNoNoNoNoNoNoNo
Years2022-2022-2022-2022-2022-2022-2022-2022-2022-2022-2022-2022-2022-2022-2022-
Engine modelFARMotion 45FARMotion 45FARMotion 45 UltraFARMotion 45 UltraFARMotion 45 UltraFARMotion 45 UltraFARMotion 45FARMotion 45FARMotion 45 UltraFARMotion 45 UltraFARMotion 45 UltraFARMotion 45 UltraFARMotion 45FARMotion 45 UltraFARMotion 45 Ultra
Cyl/Turbo/Intercooler4TI4TI4TI4TI4TI4TI4TI4TI4TI4TI4TI4TI4TI4TI4TI
Displacement3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³3849 cm³
Bore x stroke103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm103×115,5 mm
Rated power---------------
Max power---------------
Torque---------------
Gears20+20/30+3020+20/30+3030+3030+3030+3030+3020+1620+1620+1620+1620+1620+16steplesssteplessstepless
Synchronized gears20+20/30+3020+20/30+3030+3030+3030+3030+3020+1620+1620+1620+1620+1620+16steplesssteplessstepless
Powershift gears2/3-step2/3-step3-step3-step3-step3-steppowershiftpowershiftpowershiftpowershiftpowershiftpowershiftsteplesssteplessstepless
Reverserhydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.
Speeds in km/h1,2-401,2-401,2-401,2-401,2-401,2-40?-50?-50?-50?-50?-50?-500,01-500,01-500,01-50
Max. speed 40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h40/50 km/h
Hydr. flow l/min55 (90) l/min55 (90) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min90 (120) l/min
Hydraulic pressure200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar200 bar
Lift controlselec.elec.elec.elec.elec.elec.elec.elec.elec.elec.elec.elec.elec.elec.elec.
Lift capacity5410 kg5410 kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg5000 (7000) kg
PTO speeds540/1000540/1000540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400540/750/ 1000/1400
Brakeswet discwet discwet discwet discwet discwet discwet discwet discwet discwet discwet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD101010101010101010101010101010
Front tyres 4WD420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24420/70R24
Rear tyres 4WD480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34480/70R34
Weight 4WD4600 kg4600 kg5000 kg5000 kg5000 kg5000 kg5500 kg5500 kg5500 kg5500 kg5500 kg5500 kg5500 kg5500 kg5500 kg
Height with cab274 cm274 cm279 cm279 cm279 cm279 cm279 cm279 cm279 cm279 cm279 cm279 cm279 cm279 cm279 cm
Length (2WD/4WD)443 cm443 cm450 cm450 cm450 cm450 cm453 cm453 cm453 cm453 cm453 cm453 cm453 cm453 cm453 cm
Wheelbase (2WD/4WD)248 cm248 cm248 cm248 cm248 cm248 cm251 cm251 cm251 cm251 cm251 cm251 cm251 cm251 cm251 cm
Fuel tank160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l160+12AB l
Cab noise level71 dB71 dB71 dB71 dB71 dB71 dB71 dB71 dB71 dB71 dB71 dB71 dB71 dB71 dB71 dB
Solid cabxxxxxxxxxxxxxxx
Diff. lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lockdisc lock
Autom. differential locksxxxxxxxxxxxxxxx
Air suspension seatxxxxxxxxxxxxxxx
Air conditioningxxxxxxxxxxxxxxx
Creeper gearopt.opt.opt.opt.opt.opt.opt.opt.opt.opt.opt.opt.xxx
Manufacturer name------------LamborghiniLamborghiniLamborghini
