At the end of 1984, the 12-series models, i.e., the results of the "fifth modernization program," were introduced to the Finnish market. Additional power was added to the lifting device and hydraulic pump, although the performance figures remained rather modest and the lifting device was still slow as before. The engines featured new injection pumps. The rear axle housing was strengthened, and the clutch was hydraulically actuated and self-adjusting. In the 4-cylinder models, gear ratios were modified with fieldwork in mind, but the top speed still remained below 30 km/h. Sound insulation in the cabin was improved. The engine hood was beveled more than before. The ends of the drawbars were telescopic.
In the autumn of 1987, the updated successors to the 6211/6245 and 7211/7245—the 7711/7745 (73 hp)—were introduced in Finland, having been announced a couple of years earlier. The four-wheel-drive models (except the 5245) now featured hydrostatic steering and a locking differential on the front axle. Road speed was increased to 35 km/h, and the brakes were disc brakes. Towards the end of their production, four-wheel-drive versions of these models and the updated 5245 were also available with a 10+10 shuttle gearbox. The updates to disc brakes and hydrostatic steering did not apply to the 5245. The 1990 novelty was the turbocharged 7745 Special (81 hp) available as a retrofit. At the same time, a specially equipped 7745 Jubilee was also offered, which included, among other things, 1000 rpm PTO, radio, and a Grammer seat. However, the model 5211 R (35 hp) was not imported to Finland.
This is an automated translation. Please report any issues in the translation.
| Model | Zetor 5211/5245 | Zetor 5211/5245 | Zetor 6211/6245 | Zetor 6211/6245 | Zetor 7211/7245 | Zetor 7711/7745 | Zetor 7745 Special |
|---|---|---|---|---|---|---|---|
| Manufacturer name | Zetor | Zetor | Zetor | Zetor | Zetor | Zetor | Zetor |
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 1984-87 | 1987-93 | 1984-87 | 1987-93 | 1984-93 | 1985-93 | 1989-93 |
| Engine model | Z5201 | Z5201 | Z6201 | Z6201 | Z7201 | Z7701 | Z7701 |
| Cyl/Turbo/Intercooler | 3 | 3 | 4 | 4 | 4 | 4 | 4T |
| Displacement | 2696 cm³ | 2696 cm³ | 3456 cm³ | 3456 cm³ | 3595 cm³ | 3922 cm³ | 3922 cm³ |
| Bore x stroke | 102×110 mm | 102×110 mm | 100×110 mm | 100×110 mm | 102×110 mm | 102×120 mm | 102×120 mm |
| Rated power | 47/2200 hp DIN/rpm | 51/2200 hp DIN/rpm | 59/2200 hp DIN/rpm | 61/2200 hp DIN/rpm | 66/2200 hp DIN/rpm | 73/2200 hp DIN/rpm | 81/2200 hp DIN/rpm |
| Torque | - | - | - | - | - | - | - |
| Gears | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 |
| Synchronized gears | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Speeds in km/h | 1,1-25,2 | 1,2-25,3 | 1,8-26,4 | 1,9-29,7 | 1,8-26,4 | 2,1-31,2 | 2,1-31,2 |
| Hydr. flow l/min | 32 l/min | 35 l/min | 32 l/min | 34 l/min | 32 l/min | 37 l/min | 37 l/min |
| Hydraulic pressure | 160 bar | 160 bar | 160 bar | 160 bar | 160 bar | 160 bar | 160 bar |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 1750 kg | 1750 kg | 2400 kg | 2400 kg | 2400 kg | 2400 kg | 2400 kg |
| PTO speeds | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo |
| Brakes | drum brakes | drum brakes | drum brakes | dry disc | drum brakes | dry disc | dry disc |
| Steering | power | power | power | power/hydrost. | power | power/hydrost. | hydrost. |
| Turning circle m 2WD | 7.2 | 7.1 | 7.6 | 7.6 | 7.6 | 7.6 | - |
| Turning circle m 4WD | 9.5 | 9.5 | 10.4 | 10.4 | 10.4 | 10.4 | 10.4 |
| Front tyres 2WD | 7,50-16 | 7,50-16 | 7,50-20 | 7,50-20 | 7,50-20 | 7,50-20 | - |
| Front tyres 4WD | 9.5-24 | 11.2-24 | 11.2-24 | 11.2-24 | 11.2-24 | 12.4-24 | 12.4-24 |
| Rear tyres 2WD | 16,9-28 | 12,4-36 | 16,9-30 | 16,9-30 | 16,9-30 | 16,9-34 | - |
| Rear tyres 4WD | 16.9-28 | 16.9-28 | 16.9-30 | 16.9-30 | 16.9-30 | 16.9-34 | 16.9-34 |
| Weight 2WD | 2800 kg | 2800 kg | 3030 kg | 2990 kg | 3000 kg | 3130 kg | - |
| Weight 4WD | 3180 kg | 3180 kg | 3400 kg | 3430 kg | 3460 kg | 3490 kg | 3520 kg |
| Height with cab | 255 cm | 261 cm | 260 cm | 263/271 cm | 260 cm | 268/275 cm | 275 cm |
| Length (2WD/4WD) | 352 cm | 367 cm | 365 cm | 376 cm | 365 cm | 376 cm | 376 cm |
| Wheelbase (2WD/4WD) | 212/210 cm | 212 cm | 225/223 cm | 225/222 cm | 225/223 cm | 225/222 cm | 222 cm |
| Fuel tank | 55 l | 55 l | 70 l | 70 l | 70 l | 70 l | 70 l |
| Cab noise level | 80.5 dB | 84 dB | 83.5 dB | 85 dB | 83 dB | 83 dB | 82.5 dB |
| Solid cab | x | x | x | x | x | x | x |
| Reverser | - | opt. | - | opt. | - | opt. | opt. |
| Max. speed | - | 28 km/h | - | 32.5 km/h | - | 34 km/h | 34 km/h |
| Diff. lock | - | - | - | differential lock with cogs | - | differential lock with cogs | differential lock with cogs |
