Siirry sivupalkkiinSiirry alaosaanNew Holland TC 56
Manufacturer
Models
TC56 mek., TC56 hydr., TC56 mek., TC56 hydr., TC56 RS, TC56 hydr., TC56 RS, TC56 mek., TC56 hydr., TC56 RS, TC56 RS
Years
1990-99
Info
The TC 56 was the successor to the 8055-8070 models. Compared to its predecessors, the most significant changes were longer threshing bars and 7.5-liter engines. The RS model featured an after-threshing reel behind the straw reel. The decal styles shown in these pictures represent the years 1998-2001 and 2002-2004. Production was moved from Belgium to Poland in 2001-2002. In most Western European countries, models equipped with more powerful engines, the TC57 and TC59, were not sold.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | TC56 mek. | TC56 hydr. | TC56 mek. | TC56 hydr. | TC56 RS | TC56 hydr. | TC56 RS | TC56 mek. | TC56 hydr. | TC56 RS | TC56 RS |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 1991-97 | 1991-97 | 1997-99 | 1997-99 | 1997-99 | 1990-2002 | 1999-2002 | 2002-04 | 2002-06 | 2002-06 | 2006-07 |
| Engine | NH | NH | NH | NH | NH | NH | NH | NH | NH | NH | Iveco |
| Engine type | 6.75T | 6.75T | 6.75T | 6.75T | 6.75T | 6.75T | 6.75T | 675TA/HJ | 675TA/CD | 675TA/CD | NEF |
| Displacement | 7474 cm³ | 7474 cm³ | 7474 cm³ | 7474 cm³ | 7474 cm³ | 7474 cm³ | 7474 cm³ | 7474 cm³ | 7474 cm³ | 7474 cm³ | 6728 cm³ |
| Cyl/turbo | 6 T | 6 T | 6 T | 6 T | 6 T | 6 T | 6 T | 6 T | 6 T | 6 T | 6 TI |
| Power | 155 hp DIN | 155 hp DIN | 155 hp DIN | 170 hp DIN | 186 hp DIN | 182 hp DIN | 186 hp DIN | 170 hp DIN | 204 hp DIN | 204 hp DIN | 204 hp DIN |
| Fuel tank | 300 l | 300 l | 300 l | 300 l | 300 l | 300 l | 300 l | 300 l | 300 l | 300 l | 300 l |
| Transmission | mech. | hydr. | mech. | hydr. | hydr. | hydr. | hydr. | mech. | hydr. | hydr. | hydr. |
| Gears | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Speed min-max. | 1,6-25 km/h | 0-25 km/h | 1,6-25 km/h | 0-25 km/h | 0-25 km/h | 0-25 km/h | 0-25 km/h | 1,6-25 km/h | 0-25 km/h | 0-25 km/h | 0-25 km/h |
| Cutting width | 457 cm | 457 cm | 457 cm | 457 cm | 457 cm | 457 cm | 457 cm | 457 cm | 457 cm | 457 cm | 457 cm |
| Cutting width, alternative | 366-518 cm | 366-518 cm | 366-518 cm | 366-518 cm | 366-518 cm | 366-518 cm | 366-518 cm | 366-518 cm | 366-518 cm | 366-518 cm | 366-518 cm |
| Reel diameter | 107 cm | 107 cm | 107 cm | 107 cm | 107 cm | 107 cm | 107 cm | 107 cm | 107 cm | 107 cm | 107 cm |
| Header length | 41 cm | 41 cm | 41 cm | 41 cm | 41 cm | 41 cm | 41 cm | 41 cm | 41 cm | 41 cm | 41 cm |
| Threshing cyl. diameter | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm |
| Threshing cyl. width | 130 cm | 130 cm | 130 cm | 130 cm | 130 cm | 130 cm | 130 cm | 130 cm | 130 cm | 130 cm | 130 cm |
| Number of straw walkers | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Area of walkers | 500 dm² | 500 dm² | 500 dm² | 500 dm² | 436 dm² | 500 dm² | 436 dm² | 500 dm² | 500 dm² | 436 dm² | 436 dm² |
| Lenght of walkers | 378 cm | 378 cm | 378 cm | 378 cm | 330 cm | 378 cm | 330 cm | 378 cm | 378 cm | 330 cm | 330 cm |
| Straw shieve | 219 dm² | 219 dm² | 219 dm² | 219 dm² | 219 dm² | 219 dm² | 219 dm² | 219 dm² | 219 dm² | 219 dm² | 219 dm² |
| Bottom shieve | 171 dm² | 171 dm² | 171 dm² | 171 dm² | 171 dm² | 171 dm² | 171 dm² | 171 dm² | 171 dm² | 171 dm² | 171 dm² |
| Total screening area | 413 | 413 | 413 | 413 | 413 | 413 | 413 | 413 | 413 | 413 | 413 |
| Overall lenght | 932 cm | 932 cm | 932 cm | 932 cm | 932 cm | 932 cm | 932 cm | 932 cm | 932 cm | 932 cm | 932 cm |
| Overall width | 490 cm | 490 cm | 490 cm | 490 cm | 490 cm | 490 cm | 490 cm | 490 cm | 490 cm | 490 cm | 490 cm |
| Width without header | 337 cm | 337 cm | 337 cm | 337 cm | 337 cm | 337 cm | 337 cm | 335 cm | 335 cm | 335 cm | 335 cm |
| Height without cabin | 372 cm | 372 cm | 372 cm | 372 cm | 372 cm | 372 cm | 372 cm | - | - | - | - |
| Height with cabin | 380 cm | 380 cm | 380 cm | 380 cm | 380 cm | 380 cm | 380 cm | 391 cm | 391 cm | 391 cm | 391 cm |
| Weight with cabin | 9700 kg | 9700 kg | 9800 kg | 9800 kg | 10000 kg | 9800 kg | 10000 kg | 9800 kg | 9800 kg | 10000 kg | 10000 kg |
| Weight without header | 8400 kg | 8400 kg | 8520 kg | 8520 kg | 8720 kg | 8520 kg | 8720 kg | 8520 kg | 8520 kg | 8720 kg | 8720 kg |
| Grain tank | 48.3 hl | 48.3 hl | 52 hl | 52 hl | 52 hl | 52 hl | 52 hl | 52 hl | 52 hl | 52 hl | 52 hl |
| Unl. height | 394 cm | 394 cm | 394 cm | 394 cm | 394 cm | 394 cm | 394 cm | 399 cm | 399 cm | 399 cm | 399 cm |
| Tyres front (Finland) | 23.1R30 | 23.1R30 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 |
| Tyres front, alternative | 23.1-26 | - | 23.1-30 | 23.1-30 | 23.1-26 | 23.1-26 | 23.1-26 | 620/75R30 | 620/75R30 | 620/75R30 | 620/75R30 |
| Tyres rear (Finland) | 13/65-18 | 13/65-18 | 16/70-20 | 16/70-20 | 16/70-20 | 16/70-20 | 16/70-20 | 400/70-20 | 400/70-20 | 400/70-20 | 400/70-20 |
| Tyres rear, alternative | 10.5-18 | 10.5-18 | 13/65-18 | 13/65-18 | 13/65-18 | 13/65-18 | 400/70-20 | 13/65-18 | 13/65-18 | 13/65-18 | 13/65-18 |
| Reel forward/backw. adjustment | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Reel speed adjustment | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Threshing cyl. speed adjustment | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Bottom sieve | adj. | adj. | adj. | adj. | adj. | adj. | adj. | adj. | adj. | adj. | adj. |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Reverser | x | x | x | x | x | x | x | x | x | x | x |
| Type of cutting platform floating | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper |
| Heating | - | - | x | x | x | x | x | x | x | x | x |
| Grain loss indicator | - | - | x | x | x | x | x | x | x | x | x |
| 2. cyl. diameter | - | - | - | - | 61 cm | - | 61 cm | - | - | 61 cm | 61 cm |
| Slope levelling | - | - | - | - | - | - | - | opt. | opt. | opt. | opt. |
| Floating cutting platform | - | - | - | - | - | - | - | - | opt. | opt. | x |
| Autom. control of cutting height | - | - | - | - | - | - | - | - | opt. | opt. | x |
| Cutting platform lateral tilt | - | - | - | - | - | - | - | - | opt. | opt. | opt. |
| Air conditioning | - | - | - | - | - | - | - | - | - | - | x |
