Siirry sivupalkkiinSiirry alaosaanKubota L2050-L4150






The Kubota L-series introduced in 1984-1985 included about a dozen models starting from the 25-horsepower L2050, but only some of these were sold in Europe. In Finland, only the 29.5-horsepower 3-cylinder L2550 was available. In Central Europe, the most common model was the 4-cylinder L2850. Compared to previous models, the lineup featured more powerful engines relative to their external dimensions. Most models had an 8+7 gearbox with a mechanical shuttle shift, where the 3rd and 4th gears of the main range and the range shift were synchronized. The 5-cylinder L3750 and L4150 differed from the smaller models in many ways, with their most significant difference being the hydraulic shuttle on the 4150.
This is an automated translation. Please report any issues in the translation.
| Model | Kubota L2250 | Kubota L2550 | Kubota L2850 | Kubota L3250 | Kubota L3750 | Kubota L4150 |
|---|---|---|---|---|---|---|
| Manufacturer name | Kubota | Kubota | Kubota | Kubota | Kubota | Kubota |
| Imported to Finland | No | Yes | No | No | No | No |
| Years | 1985-91 | 1985-93 | 1985-93 | 1989-90 | 1984-90 | 1984-90 |
| Engine model | D1302-DI-A | D1402-DI-A | V1702DI-A | V1902DI-AE | F2302DI-L | F2302DI |
| Cyl/Turbo/Intercooler | 3 | 3 | 4 | 4 | 5 | 5 |
| Displacement | 1299 cm³ | 1395 cm³ | 1732 cm³ | 1861 cm³ | 2326 cm³ | 2326 cm³ |
| Bore x stroke | 82×82 mm | 85×82 mm | 82×82 mm | 85×82 mm | 85×82 mm | 85×82 mm |
| Rated power | 26/2800 hp DIN/rpm | 29,5/2850 hp DIN/rpm | 38/2400 hp DIN/rpm | 40/2600 hp DIN/rpm | 45/2500 hp DIN/rpm | 50/2600 hp DIN/rpm |
| Gears | 8+7 | 8+7 (16+14) | 8+7 (16+14) | 8+7 (16+14) | 8+8 (16+16) | 8+8 (16+16) |
| Synchronized gears | 4+3 | 4+3 | 4+3 | 4+3 | 4+4 | 4+4 |
| Reverser | mech. | mech. | mech. | mech. | mech. | hydr. |
| Speeds in km/h | 1,4-20,8 | 2,0-26,1 | 1,4-25,6 | 1,4-22,3 | 1,6-22,8 | 1,7-24,9 |
| Hydr. flow l/min | 17 (27) l/min | 27 l/min | 29.5 l/min | 29.5 l/min | 36 l/min | 36 l/min |
| Hydraulic pressure | 155 bar | 155 bar | 160 bar | 160 bar | 175 bar | 175 bar |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 700 kg | 900 kg | 1400 kg | 1400 kg | 1650 kg | 1650 kg |
| PTO speeds | 540/700/1000 | 540/700/1000 | 540/1000 | 540/1000 | 540/750 | 540/750 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | mech. (power) | power | power | power | hydrost. | hydrost. |
| Front tyres 2WD | 4.00-15 | - | - | - | - | - |
| Front tyres 4WD | 6-14 | 7-16 | 7-16 | 8-16 | 9.50-16 | 9.50-20 |
| Rear tyres 2WD | 9.5-24 | - | - | - | - | - |
| Rear tyres 4WD | 9.5-24 | 11.2-24 | 13.6-24 | 13.6-26 | 13.6-28 | 14.9-28 |
| Weight 2WD | (985) kg | - | - | - | - | - |
| Weight 4WD | (1080) kg | 1410 kg | 1480 kg | 1500 kg | 1900 kg | 1950 kg |
| Length (2WD/4WD) | 275 cm | 277 cm | 290 cm | 295 cm | 349 cm | 349 cm |
| Wheelbase (2WD/4WD) | 164 cm | 164 cm | 173 cm | 173 cm | 194 cm | 194 cm |
| Fuel tank | 29 l | 29 l | 29 l | 29 l | 58 l | 58 l |
| Turning circle m 4WD | - | 4,6 jarrulla | 4,8 jarrulla | 5,0 jarrulla | 6,2 jarrulla | 6,2 jarrulla |
| Height with cab | - | 229 cm | 220 cm | 220 cm | 215 cm | 215 cm |
| Cab noise level | - | 83 dB | 83 dB | 83 dB | 83 dB | 83 dB |
| Solid cab | - | x | x | x | x | x |
| Torque | - | - | - | - | - | - |
| Creeper gear | - | - | opt. | opt. | opt. | opt. |
