Agco White 6124-6215

Manufacturer
Models
Agco White 6124, Agco White 6125, Agco White 6144, Agco White 6145, Agco White 6175, Agco White 6195, Agco White 6215
Years
1992-99
Info

After the White tractors moved to Agco ownership, a new Agco White Workhorse series was quickly introduced to the market at the end of 1992. Agco was replacing its Deutz-based products in the Allis lineup with a new series, into which the Whites were also integrated. The Agco White 6125-6195 corresponded to the Agco Allis models 9130-9190. The Agco White was powered by Cummins engines and had a silver color. The engines in the orange Agco Allis models were initially air-cooled Deutz, and from 1995 onward, a series of Detroit Diesel engines, which had roots in International Harvester. In Europe, the same tractor was sold under the Massey Ferguson 9240 name as well as the Same 265 and, painted white, as the Lamborghini Traction 220/240/265. In addition, the Deutz-Fahr Agrostar 8.31 was partly based on the same technology.

The engine was a 5.9-liter in the two smaller models and an 8.3-liter Cummins in the larger ones. The transmission was an 18+9 speed full powershift Funk gearbox. The controls for the powershift and the hitch were placed on the armrest. The hydraulics were load-sensing, but the lifting capacity was low relative to the tractor's power class. The front axle was manufactured by ZF. The cab was similar to that of the previous White tractors but placed further forward. An air-suspended seat and air conditioning were standard.

For the 1995 model year, a more powerful 6215 was introduced along with the 6124 and 6144 models, which corresponded to the smallest in the lineup but were equipped with MF’s 32+32-speed transmission, called Quadrashift by White. At the same time, the MF rear axle brought more powerful hydraulics than what was customary in America.

From 1998 onward, the White models were replaced by MF’s French tractors under the name Agco White 6410-8810 and similarly Agco Allis 8745-9785. This continued until 2001. After that, only orange Agco tractors, red Massey Fergusons, and yellow Challengers were sold.

back

This is an automated translation. Please report any issues in the translation.

Technical data
ModelAgco White 6124Agco White 6125Agco White 6144Agco White 6145Agco White 6175Agco White 6195Agco White 6215
Manufacturer nameAgco WhiteAgco WhiteAgco WhiteAgco WhiteAgco WhiteAgco WhiteAgco White
Imported to FinlandNoNoNoNoNoNoNo
Years1994-991992-991994-991992-991992-991992-991994-99
Engine model6BT5.96BT5.96BTA5.96BTA5.96CT8.36CTA8.36CTA8.3
Cyl/Turbo/Intercooler6T6T6TA6TA6T6TA6TA
Displacement5883 cm³5883 cm³5883 cm³5883 cm³8270 cm³8270 cm³8270 cm³
Bore x stroke98,4×127 mm98,4×127 mm98,4×127 mm98,4×127 mm114×135 mm114×135 mm114×135 mm
Rated power-------
Gears32+3218+918+918+918+918+918+9
Synchronized gears32+32powershiftpowershiftpowershiftpowershiftpowershiftpowershift
Powershift gearshydr.powershiftpowershiftpowershiftpowershiftpowershiftpowershift
Reverserhydr.hydr.hydr.hydr.hydr.hydr.hydr.
Speeds in km/h2,0-36,22,4-36,22,0-36,22,4-36,22,4-36,22,4-36,22,7-39,8
Max. speed 40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h
Hydr. flow l/min102 l/min83 l/min102 l/min83 l/min83 l/min83 l/min98.4 l/min
Hydraulic pressure200 bar155 bar200 bar155 bar172 bar172 bar193 bar
Lift controlselec.elec.elec.elec.elec.elec.elec.
Lift capacity4717 kg3271 (3876) kg4717 kg3271 (3876) kg3856 (4491) kg4491 kg6350 kg
PTO speeds540/1000540/1000540/1000540/1000100010001000
Brakeswet discwet discwet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 2WD9.399.399.399.399.81--
Turning circle m 4WD10.4810.4810.4810.4812.2512.2512.25
Front tyres 2WD11.00-1611.00-1611.00-1611.00-1611.00-16--
Front tyres 4WD14.9R2814.9R2814.9R2814.9R2816.9R2816.9R2816.9R28
Rear tyres 2WD18.4R3818.4R3818.4R3818.4R3820.8R38--
Rear tyres 4WD18.4R3818.4R3818.4R3818.4R3820.8R3820.8R3820.8R38
Weight 2WD6260 kg6260 kg6260 kg6260 kg6713 kg--
Weight 4WD6985 kg6985 kg6985 kg6985 kg7711 kg7756 kg7847 kg
Height with cab302 cm302 cm302 cm302 cm301 cm301 cm302 cm
Length (2WD/4WD)456 cm456 cm456 cm456 cm475/480 cm480 cm480 cm
Wheelbase (2WD/4WD)292/269 cm292/269 cm292/269 cm292/269 cm302/292 cm292 cm287 cm
Fuel tank254 l254 l254 l254 l367 l367 l367 l
Cab noise level77 dB77 dB77 dB77 dB75.5 dB75.5 dB75.5 dB
Solid cabxxxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lock
Air suspension seatxxxxxxx
Air conditioningxxxxxxx
