Siirry sivupalkkiinSiirry alaosaanSame 240 – 480

In 1958, a new Same series was introduced, in which the model number indicated the number of cylinders and power class. The smallest model in the lineup, Sametto, also received the model number 120. The hood was higher than before, and the green parts were painted gray. The orange color was darker than before.
The engines were air-cooled direct injection diesels based on the previous models, with the cylinder diameter increased to 115 millimeters. There were more gears than before. The 240’s lifting device featured a draft control called SAC. This only came to the larger models in 1960.
In 1961, the 240 was replaced by the more powerful 250, which was three horsepower stronger. Its four-wheel-drive model had power transmission through a central shaft.
The 1963 Same 360 C featured a new 9+2 speed transmission and 65 hp. The 480 was renamed the updated Ariete 480. The power transmission was a completely new 8+4 speed system, and it had 85 hp. The four-wheel-drive model came standard with power-assisted steering.
The 450 V, which replaced the 250 and was only in production for a couple of years, had a 50-horsepower V4 engine.
This is an automated translation. Please report any issues in the translation.
| Model | Same 240 | Same 450 V | Same 360 | Same 360 C | Same 480 | Same Ariete 480 |
|---|---|---|---|---|---|---|
| Manufacturer name | Same | Same | Same | Same | Same | Same |
| Imported to Finland | No | No | No | No | No | No |
| Years | 1958-61 | 1963-65 | 1958-62 | 1963-67 | 1959-62 | 1963-67 |
| Engine model | DA 1152 | DA 954/V | DA 1153 | DA 1153 | DA 1154 | DA 1154 |
| Cyl/Turbo/Intercooler | 2 | V4 | 3 | 3 | 4 | 4 |
| Displacement | 2490 cm³ | 3400 cm³ | 3735 cm³ | 3735 cm³ | 4980 cm³ | 4980 cm³ |
| Bore x stroke | 115×120 mm | 95×120 mm | 115×120 mm | 115×120 mm | 115×120 mm | 115×120 mm |
| Rated power | 42/2000 hp DIN/rpm | 50/2000 hp DIN/rpm | 62/2000 hp DIN/rpm | 65/2000 hp DIN/rpm | 82/2000 hp DIN/rpm | 85/2000 hp DIN/rpm |
| Gears | 6+1 | 6+1 | 5+1/8+2 | 9+2 | 5+1/8+2 | 8+4 |
| Speeds in km/h | 1,1-25,0 | 1,3-29,4 | 2,8-23,4/ 3,2-24,8 | 1,5-29,2 | 1,8-23,5 | 2,2-24,7 |
| Max. speed | 29 km/h | - | 25 km/h | - | 25 km/h | - |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. |
| PTO speeds | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo |
| Brakes | drum brakes | drum brakes | drum brakes | drum brakes | drum brakes | drum brake/disc brake |
| Steering | mech. | mech. | mech. | mech. | mech. | mech./power |
| Turning circle m 2WD | 5.8 | - | - | 6.6 | - | - |
| Turning circle m 4WD | 7.8 | - | 8.6 | 7.8 | - | - |
| Front tyres 2WD | 6.00-16 | 6.00-16 | 6.00-19 | 6.00-19 | 7.50-18 | 7.50-18 |
| Front tyres 4WD | 7.50-20 | 7.50-20 | 9.5-24 | 9.5-24 | 12.4-24 | 12.4-24 |
| Rear tyres 2WD | 12.4-28 | 12.4-28 | 14.9-28 | 14.9-28 | 16.9-30 | 16.9-30 |
| Rear tyres 4WD | 12.4-28 | 11.2-28 | 13.6-28 | 14.9-28 | 16.9-30 | 16.9-30 |
| Weight 2WD | (1680) kg | (1730) kg | (2400) kg | (2600) kg | (2700) kg | - |
| Weight 4WD | (1910) kg | (1920) kg | (2750) kg | (2900) kg | (3100) kg | - |
| Height with cab | (148) cm | (149/147) cm | (163) cm | (160) cm | (168) cm | (175) cm |
| Length (2WD/4WD) | 284/295 cm | 281/286 cm | 302/307 cm | 307/315 cm | 340/343 cm | 360/372 cm |
| Wheelbase (2WD/4WD) | 185/184 cm | 184/183 cm | 201/195 cm | 200/195 cm | 211/209 cm | 237 cm |
| Fuel tank | 31/50 l | - | 36/70 l | 70 l | 70 l | - |
| Diff. lock | no | no | no | no | no | no |
| Hydr. flow l/min | - | - | 20 l/min | 24 l/min | 11.5 l/min | 28 l/min |
| Hydraulic pressure | - | - | 175 bar | 175 bar | - | 175 bar |
| Lift capacity | - | - | - | 1700 kg | 1800 kg | 2400 kg |
