Siirry sivupalkkiinSiirry alaosaanSame Explorer 60-90
Manufacturer
Models
Same Explorer 60, Same Explorer 70, Same Explorer 80, Same Explorer 90
Years
1986-90
Info
In the fall of 1986, the Explorers equipped with new engines were introduced: a 3.0-liter 60 and 4.0-liter 70, 80, and 90. Models with the new engines had already been introduced slightly earlier on Lamborghinis and Hürlimanns. The Explorer 90 featured a new 20+20 transmission, which enabled a speed of 40 km/h. In 1988, the Same Dual Trac was introduced, which could be switched to operate in reverse in 30 seconds by turning the seat and moving the detached steering wheel to the rear end.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Same Explorer 60 | Same Explorer 70 | Same Explorer 80 | Same Explorer 90 |
|---|---|---|---|---|
| Manufacturer name | Same | Same | Same | Same |
| Imported to Finland | No | Yes | Yes | Yes |
| Years | 1986-90 | 1986-90 | 1986-90 | 1986-90 |
| Engine model | 1000.3A | 1000.4A | 1000.4A | 1000.4AT |
| Cyl/Turbo/Intercooler | 3 | 4 | 4 | 4T |
| Displacement | 3000 cm³ | 4000 cm³ | 4000 cm³ | 4000 cm³ |
| Bore x stroke | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm |
| Rated power | 60/2500 hp DIN/rpm | 70/2350 hp DIN/rpm | 80/2500 hp DIN/rpm | 90/2500 hp DIN/rpm |
| Torque | - | - | - | - |
| Gears | 12+12 | 12+12 | 24+12 | 20+20 |
| Synchronized gears | 12+12 | 12+12 | 24+12 | 20+20 |
| Reverser | mech. | mech. | mech. | mech. |
| Speeds in km/h | 1,2-28,0 | 1,2-28,0 | 1,1-28,6 | 0,4-39,0 |
| Hydr. flow l/min | 29 l/min | 35 l/min | 35 (42,5) l/min | 35 (42,5) l/min |
| Hydraulic pressure | 183 bar | 183 bar | 183 bar | 183 bar |
| Lift controls | mech. | mech. | mech. | mech. |
| Lift capacity | 2270 kg | 3430 kg | 3430 (5140) kg | 3430 (5140) kg |
| PTO speeds | 540/1000/ajo | 540/1000/ajo | 540/1000/ajo | 540/1000/ajo |
| Brakes | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 7.8 | 8 | 8.2 | 8.3 |
| Front tyres 4WD | 11.2-24 | 12.4-28 | 14.9-24 | 13.6-28 |
| Rear tyres 4WD | 14.9-30 | 13.6-38 | 16.9-34 | 18.4-34 |
| Weight 4WD | 2955 kg | 3075 kg | 3300 kg | 3430 kg |
| Height with cab | 251 cm | 244 cm | 244 cm | 244 cm |
| Length (2WD/4WD) | 384 cm | 399 cm | 399 cm | 399 cm |
| Wheelbase (2WD/4WD) | 212 cm | 233/229 cm | 242/232 cm | 242/232 cm |
| Fuel tank | 85 l | 100 l | 110 l | 110 l |
| Cab noise level | 84 dB | 84 dB | 84 dB | 84 dB |
| Solid cab | x | x | x | x |
| Diff. lock | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs |
| Creeper gear | opt. | opt. | opt. | x |
| Turning circle m 2WD | - | 7.1 | 7.1 | 7.1 |
| Front tyres 2WD | - | 7,50-16 | 7,50-18 | 7,50-18 |
| Rear tyres 2WD | - | 16,9-30 | 16,9-34 | 16,9-34 |
| Weight 2WD | - | 2780 kg | 2780 kg | - |
| Powershift gears | - | - | mech. | - |
