Siirry sivupalkkiinSiirry alaosaanSame Explorer3 75-95 / Lamborghini R3.75-R3.95 / Hürlimann XB 75-95








For the year 2004, the biggest changes in the company’s history were made to the Explorer and its sister models. The engines of the Same machines were now also water‐cooled, so the differences between the brands were limited to styling and minor equipment variations. There were four gearbox options. Without a power shuttle there were 15+15 gears, and with creeper gears 20+20. Using a three‐stage hydraulic power shuttle, the counts rose to 45+45 and 60+60. For the first time a hydraulic directional shuttle was available. Lift capacity was 4.8 tonnes, or 6.2 tonnes with auxiliary cylinders. The 160-litre fuel tank was considerably larger than before. The cab was completely redesigned and had a noise level of 75 dB. As an option, you could have automatic engagement for the four‐wheel drive and differential locks.
This is an automated translation. Please report any issues in the translation.
| Model | Same Explorer3 75 | Lamborghini R3.75 | Same Explorer3 85 | Lamborghini R3.85 | Same Explorer3 95 | Lamborghini R3.95 |
|---|---|---|---|---|---|---|
| Imported to Finland | No | No | No | No | No | No |
| Years | 2004-07 | 2004-07 | 2004-07 | 2004-07 | 2004-07 | 2004-07 |
| Engine model | 1000.4W | 1000.4W | 1000.4WT | 1000.4WT | 1000.4WT | 1000.4WT |
| Cyl/Turbo/Intercooler | 4 | 4 | 4T | 4T | 4T | 4T |
| Displacement | 4000 cm³ | 4000 cm³ | 4000 cm³ | 4000 cm³ | 4000 cm³ | 4000 cm³ |
| Bore x stroke | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm |
| Rated power | 71/2300 hp DIN/rpm | 71/2300 hp DIN/rpm | 81/2300 hp DIN/rpm | 81/2300 hp DIN/rpm | 90/2500 hp DIN/rpm | 90/2500 hp DIN/rpm |
| Torque | - | - | - | - | - | - |
| Gears | 20+20/60+60 | 20+20/60+60 | 20+20/60+60 | 20+20/60+60 | 20+20/60+60 | 20+20/60+60 |
| Synchronized gears | 20+20/60+60 | 20+20/60+60 | 20+20/60+60 | 20+20/60+60 | 20+20/60+60 | 20+20/60+60 |
| Powershift gears | -/3-step | -/3-step | -/3-step | -/3-step | -/3-step | -/3-step |
| Reverser | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) |
| Speeds in km/h | 0,5-37,9/ 0,34-37,9 | 0,5-37,9/ 0,34-37,9 | 0,5-37,9/ 0,34-37,9 | 0,5-37,9/ 0,34-37,9 | 0,5-37,9/ 0,34-37,9 | 0,5-37,9/ 0,34-37,9 |
| Max. speed | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h |
| Hydr. flow l/min | 54 l/min | 54 l/min | 54 l/min | 54 l/min | 54 l/min | 54 l/min |
| Hydraulic pressure | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar |
| Lift controls | mech. (elec.) | mech. (elec.) | mech. (elec.) | mech. (elec.) | mech. (elec.) | mech. (elec.) |
| Lift capacity | 4800 (6200) kg | 4800 (6200) kg | 4800 (6200) kg | 4800 (6200) kg | 4800 (6200) kg | 4800 (6200) kg |
| PTO speeds | 540/750/ 1000/1250 | 540/750/ 1000/1250 | 540/750/ 1000/1250 | 540/750/ 1000/1250 | 540/750/ 1000/1250 | 540/750/ 1000/1250 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 9.26 | 9.26 | 9.26 | 9.26 | 9.26 | 9.26 |
| Front tyres 4WD | 14.9R24 | 14.9R24 | 14.9R24 | 14.9R24 | 14.9R24 | 14.9R24 |
| Rear tyres 4WD | 16.9R34 | 16.9R34 | 16.9R34 | 16.9R34 | 18.4R34 | 18.4R34 |
| Weight 4WD | 3730 kg | 3730 kg | 3800 kg | 3800 kg | 3900 kg | 3900 kg |
| Height with cab | 263 cm | 263 cm | 263 cm | 263 cm | 265 cm | 265 cm |
| Length (2WD/4WD) | 417 cm | 417 cm | 417 cm | 417 cm | 417 cm | 417 cm |
| Wheelbase (2WD/4WD) | 236 cm | 236 cm | 236 cm | 236 cm | 236 cm | 236 cm |
| Fuel tank | 160 l | 160 l | 160 l | 160 l | 160 l | 160 l |
| Cab noise level | 75 dB | 75 dB | 75 dB | 75 dB | 75 dB | 75 dB |
| Solid cab | x | x | x | x | x | x |
| Diff. lock | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs |
| Creeper gear | x | x | x | x | x | x |
