Siirry sivupalkkiinSiirry alaosaanSame Iron 115-135 Continuo / Lamborghini R6.115-R6.135 VRT / Hürlimann 115-135 VRT
Manufacturer
Models
Same Iron 115 Continuo, Lamborghini R6.115 VRT, Same Iron 125 Continuo, Lamborghini R6.125 VRT, Same Iron 135 Continuo, Lamborghini R6.135 VRT
Years
2011-12
Info
In the autumn of 2011, parallel models of the Deutz-Fahr TTV 410-430 were introduced in the Same and Lamborghini lineups. The transmission was a stepless ZF Eccom 1.3, and the hydraulics featured a load-sensing 120 l/min pump. The Italian versions were in production for only one year.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Same Iron 115 Continuo | Lamborghini R6.115 VRT | Same Iron 125 Continuo | Lamborghini R6.125 VRT | Same Iron 135 Continuo | Lamborghini R6.135 VRT |
|---|---|---|---|---|---|---|
| Imported to Finland | No | No | No | No | No | No |
| Years | 2011-12 | 2011-12 | 2011-12 | 2011-12 | 2011-12 | 2011-12 |
| Engine model | TCD2012L04 | TCD2012L04 | TCD2012L04 | TCD2012L04 | TCD2012L04 | TCD2012L04 |
| Cyl/Turbo/Intercooler | 4TI | 4TI | 4TI | 4TI | 4TI | 4TI |
| Displacement | 4038 cm³ | 4038 cm³ | 4038 cm³ | 4038 cm³ | 4038 cm³ | 4038 cm³ |
| Bore x stroke | 101×126 mm | 101×126 mm | 101×126 mm | 101×126 mm | 101×126 mm | 101×126 mm |
| Rated power | - | - | - | - | - | - |
| Max power | - | - | - | - | - | - |
| Torque | - | - | - | - | - | - |
| Gears | stepless | stepless | stepless | stepless | stepless | stepless |
| Synchronized gears | stepless | stepless | stepless | stepless | stepless | stepless |
| Powershift gears | stepless | stepless | stepless | stepless | stepless | stepless |
| Reverser | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Speeds in km/h | 0,05-40/50 | 0,05-40/50 | 1,6-42,0/49,1 | 1,6-42,0/49,1 | 1,7-42,0/49,1 | 1,7-42,0/49,1 |
| Max. speed | 50 (40) km/h | 50 (40) km/h | 50 (40) km/h | 50 (40) km/h | 50 (40) km/h | 50 (40) km/h |
| Hydr. flow l/min | 120 l/min | 120 l/min | 120 l/min | 120 l/min | 120 l/min | 120 l/min |
| Hydraulic pressure | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar |
| Lift controls | elec. | elec. | elec. | elec. | elec. | elec. |
| Lift capacity | 6200 kg | 6200 kg | 6200 kg | 6200 kg | 6200 kg | 6200 kg |
| PTO speeds | 540/750/ 1000/1400 | 540/750/ 1000/1400 | 540/750/ 1000/1400 | 540/750/ 1000/1400 | 540/750/ 1000/1400 | 540/750/ 1000/1400 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 9.3 | 9.3 | 9.3 | 9.3 | 9.3 | 9.3 |
| Front tyres 4WD | 480/70R24 | 480/70R24 | 480/70R24 | 480/70R24 | 480/70R28 | 480/70R28 |
| Rear tyres 4WD | 520/70R38 | 520/70R38 | 520/70R38 | 520/70R38 | 580/70R38 | 580/70R38 |
| Weight 4WD | 5500 kg | 5500 kg | 5500 kg | 5500 kg | 5500 kg | 5500 kg |
| Height with cab | 294 cm | 294 cm | 294 cm | 294 cm | 294 cm | 294 cm |
| Length (2WD/4WD) | 454 cm | 454 cm | 454 cm | 454 cm | 454 cm | 454 cm |
| Wheelbase (2WD/4WD) | 242 cm | 242 cm | 242 cm | 242 cm | 242 cm | 242 cm |
| Fuel tank | 180 l | 180 l | 180 l | 180 l | 180 l | 180 l |
| Cab noise level | 73 dB | 73 dB | 73 dB | 73 dB | 73 dB | 73 dB |
| Solid cab | x | x | x | x | x | x |
| Diff. lock | friction lock | friction lock | friction lock | friction lock | friction lock | friction lock |
| Air suspension seat | x | x | x | x | x | x |
| Air conditioning | x | x | x | x | x | x |
| Creeper gear | x | x | x | x | x | x |
