Siirry sivupalkkiinSiirry alaosaanSame Iron 175 S-210 / Lamborghini R7.175 S-R7.210






The Same Rubin was replaced in 2003 by the Iron series. Similarly, for Lamborghini, the Champion became the R7. The third sibling model was the Deutz-Fahr Agrotron 200. The Same engines were replaced by Deutz’s 7.1-liter engines. The two smaller models featured an extra power function during transport. The transmission was the same 9-speed with a quick shift used in the predecessors, but now, thanks to the creep gear range, it had 27+27 speeds. The top speed was limited to 40 km/h, achieved at 2100 rpm. The transmission included quick-shift automation with Eco and Power programs. The hydraulics were load-sensing, providing a full lifting capacity of 10 tons. Standard equipment included, among others, 100% front axle lock, disc brakes also on the front axle, differential lock automation, and headland automation. Optional extras included front axle suspension and pneumatic cab suspension.
At the beginning of 2004, the engines were updated. The 175 S gained more power, so the 190 S soon disappeared from the lineup. At the same time, Classic/Target models were introduced, with reduced features. For example, the hydraulics were based on a 73 l/min gear pump.
In 2006, the only model was the 210, equipped with common rail injection. The headland automation was more versatile than before.
This is an automated translation. Please report any issues in the translation.
| Model | Same Iron 175 S | Lamborghini R7.175 S | Same Iron 190 S | Lamborghini R7.190 S | Same Iron 200 | Lamborghini R7.200 | Same Iron 175 S Classic | Lamborghini R7.175 S Target | Same Iron 175 S | Lamborghini R7.175 S | Same Iron 190 S | Lamborghini R7.190 S | Same Iron 200 | Lamborghini R7.200 | Same Iron 210 | Lamborghini R7.210 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Imported to Finland | No | No | No | No | No | No | No | No | No | No | No | No | No | No | No | No |
| Years | 2003-04 | 2003-04 | 2003-04 | 2003-04 | 2003-04 | 2003-04 | 2004-05 | 2004-05 | 2004-05 | 2004-05 | 2004-04 | 2004-04 | 2004-06 | 2004-06 | 2006-09 | 2006-09 |
| Engine model | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | BF6M1013EC | TCD2013L06 2V DCR | TCD2013L06 2V DCR |
| Cyl/Turbo/Intercooler | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI |
| Displacement | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ | 7146 cm³ |
| Bore x stroke | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm | 108×130 mm |
| Rated power | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Torque | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Gears | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 18+18 | 18+18 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 |
| Synchronized gears | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 18+18 | 18+18 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 | 27+27 |
| Powershift gears | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step | 9-step |
| Reverser | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Speeds in km/h | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 2,6-40,0 | 2,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 | 0,6-40,0 |
| Max. speed | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h |
| Hydr. flow l/min | 113 l/min | 113 l/min | 113 l/min | 113 l/min | 113 l/min | 113 l/min | 73 l/min | 73 l/min | 113 l/min | 113 l/min | 113 l/min | 113 l/min | 113 l/min | 113 l/min | 113 l/min | 113 l/min |
| Hydraulic pressure | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar |
| Lift controls | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Lift capacity | 10000 kg | 10000 kg | 10000 kg | 10000 kg | 10000 kg | 10000 kg | 8600 kg | 8600 kg | 10000 kg | 10000 kg | 10000 kg | 10000 kg | 10000 kg | 10000 kg | 10000 kg | 10000 kg |
| PTO speeds | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 11.6 | 11.6 | 11.6 | 11.6 | 11.6 | 11.6 | 11.3 | 11.3 | 11.3 | 11.3 | 11.3 | 11.3 | 11.3 | 11.3 | 11.3 | 11.3 |
| Front tyres 4WD | 540/65R30 | 540/65R30 | 480/70R34 | 480/70R34 | 540/65R34 | 540/65R34 | 540/65R30 | 540/65R30 | 480/70R34 | 480/70R34 | 480/70R34 | 480/70R34 | 540/65R34 | 540/65R34 | 540/65R34 | 540/65R34 |
| Rear tyres 4WD | 650/65R38 | 650/65R38 | 580/70R42 | 580/70R42 | 650/65R42 | 650/65R42 | 650/65R38 | 650/65R38 | 580/70R42 | 580/70R42 | 580/70R42 | 580/70R42 | 650/65R42 | 650/65R42 | 650/65R42 | 650/65R42 |
| Weight 4WD | 7350 kg | 7350 kg | 7450 kg | 7450 kg | 7450 kg | 7450 kg | 7350 kg | 7350 kg | 7450 kg | 7450 kg | 7450 kg | 7450 kg | 7520 kg | 7520 kg | 7520 kg | 7520 kg |
| Height with cab | 292 cm | 292 cm | 297 cm | 297 cm | 297 cm | 297 cm | 292 cm | 292 cm | 297 cm | 297 cm | 297 cm | 297 cm | 302 cm | 302 cm | 302 cm | 302 cm |
| Length (2WD/4WD) | 495 cm | 495 cm | 500 cm | 500 cm | 500 cm | 500 cm | 495 cm | 495 cm | 500 cm | 500 cm | 500 cm | 500 cm | 500 cm | 500 cm | 500 cm | 500 cm |
| Wheelbase (2WD/4WD) | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm | 299 cm |
| Fuel tank | 380 l | 380 l | 380 l | 380 l | 380 l | 380 l | 250 l | 250 l | 380 l | 380 l | 380 l | 380 l | 380 l | 380 l | 380 l | 380 l |
| Cab noise level | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB | 72 dB |
| Solid cab | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x |
| Diff. lock | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs |
| Autom. differential locks | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x |
| Air suspension seat | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x |
| Air conditioning | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x |
| Trip computer | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x | x |
| Creeper gear | x | x | x | x | x | x | - | - | x | x | x | x | x | x | x | x |
