Siirry sivupalkkiinSiirry alaosaanNew Holland T6010-T6050 Delta






The changes in the T6000 Delta series, introduced in spring 2007, compared to the TSA Delta models presented a couple of years earlier, were minimal. The engine values were close to the previous ones, with slight setbacks in torque values and the power of the largest model. The transmissions offered the familiar three options: Synchro Command without a powershift, Dual Command with a 2-speed powershift, and Electro Command with a 4-speed powershift. In Finland, the focus was mainly on Electro Command. The lifting capacity in the larger models was reduced to the smaller models' level of 5200 kilograms. The electric lift device was now standard in all models in Finland. The hydraulic system was open in the Delta models. Three hydraulic valves were standard. The cab was lower than in the rest of the series but, apart from trimmed-down equipment, roughly corresponded to the rest of the series. The pillar exhaust pipe was now a standard feature. The Delta series was withdrawn from the Finnish market in 2009. The equivalent version in the UK market was called LS, but it featured a 24+24 transmission and a higher lifting capacity as standard.
This is an automated translation. Please report any issues in the translation.
| Model | New Holland T6010 Delta | New Holland T6020 Delta | New Holland T6030 Delta | New Holland T6050 Delta |
|---|---|---|---|---|
| Manufacturer name | New Holland | New Holland | New Holland | New Holland |
| Imported to Finland | Yes | Yes | Yes | Yes |
| Years | 2007-12 | 2007-12 | 2007-12 | 2007-12 |
| Engine model | NEF | NEF | NEF | NEF |
| Cyl/Turbo/Intercooler | 4T | 4TI | 6TI | 6TI |
| Displacement | 4485 cm³ | 4485 cm³ | 6728 cm³ | 6728 cm³ |
| Bore x stroke | 104×132 mm | 104×132 mm | 104×132 mm | 104×132 mm |
| Rated power | - | - | - | - |
| Torque | - | - | - | - |
| Gears | 12+12/24+24/16+16 | 12+12/24+24/16+16 | 12+12/24+24/16+16 | 12+12/24+24/16+16 |
| Synchronized gears | 12+12/24+24/16+16 | 12+12/24+24/16+16 | 12+12/24+24/16+16 | 12+12/24+24/16+16 |
| Powershift gears | -/2/4-step | -/2/4-step | -/2/4-step | -/2/4-step |
| Reverser | mech./hydr./hydr. | mech./hydr./hydr. | mech./hydr./hydr. | mech./hydr./hydr. |
| Speeds in km/h | 2,0-37,1 / 1,6-37,1 / 2,4-39,0 | 2,0-37,1 / 1,6-37,1 / 2,4-39,0 | 2,0-37,1 / 1,6-37,1 / 2,4-39,0 | 2,0-37,1 / 1,6-37,1 / 2,4-39,0 |
| Max. speed | 40 km/h | 40 km/h | 40 km/h | 40 km/h |
| Hydr. flow l/min | 63 l/min | 63 l/min | 63 l/min | 63 l/min |
| Hydraulic pressure | 190 bar | 190 bar | 190 bar | 190 bar |
| Lift controls | elec. | elec. | elec. | elec. |
| Lift capacity | 5240 kg | 5240 kg | 5240 kg | 5240 kg |
| PTO speeds | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Brakes | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 8.08 | 8.08 | 8.71 | 8.71 |
| Front tyres 4WD | 13.6R28 | 14.9R28 | 14.9R28 | 14.9R28 |
| Rear tyres 4WD | 16.9R38 | 18.4R38 | 18.4R38 | 18.4R38 |
| Weight 4WD | 4740 kg | 4760 kg | 5030 kg | 5030 kg |
| Height with cab | 272 cm | 277 cm | 277 cm | 277 cm |
| Length (2WD/4WD) | 429 cm | 429 cm | 453 cm | 453 cm |
| Wheelbase (2WD/4WD) | 241 cm | 241 cm | 265 cm | 265 cm |
| Fuel tank | 180 l | 180 l | 254 l | 254 l |
| Cab noise level | 73 dB | 73 dB | 73 dB | 73 dB |
| Solid cab | x | x | x | x |
| Diff. lock | friction lock | friction lock | friction lock | friction lock |
| Creeper gear | opt. | opt. | opt. | opt. |
